Honda PC50A MOTORCYCLE, JPN, VIN# PC50-1057918 AIR CLEANER Diagram

ELEMENT, AIR CLEANER

17205-063-020

Unavailable

HOUSING, AIR CLEANER *R8* (BRIGHT RED) (NOT AVAILABLE)

17225-063-020AW

Unavailable

CASE, CLEANER *B3L* (SKY BLUE) (NOT AVAILABLE)

17225-063-020XE

Unavailable

GASKET, INLET TUBE (NOT AVAILABLE)

17227-063-010

Unavailable

TUBE, AIR CLEANER INLET

17251-063-010

Unavailable

TUBE, AIR CLEANER CONNECTING (NOT AVAILABLE)

17253-063-010

Unavailable

CLIP, CLEANER CONNECTING TUBE (NOT AVAILABLE)

17255-063-000

Unavailable

COVER, CARBURETOR *R8* (BRIGHT RED) (NOT AVAILABLE)

17260-063-020AW

Unavailable

COVER, CARBURETOR *B3L* (SKY BLUE) (NOT AVAILABLE)

17260-063-020XE

Unavailable

SCREW, PAN (6X20) This part replaces 93500-06020.

93500-06020-0A

$1.49

SCREW, PAN (6X20)

93500-06020-0A

$1.49

WASHER, PLAIN (6MM) This part replaces 94101-06000.

94101-06800

$1.49

WASHER, PLAIN (6MM) This part replaces 94101-06080.

94101-06800

$1.49

WASHER, PLAIN (6MM)

94101-06800

$1.49
