Polaris PATRIOT BOOST INDY VR1 129 ALL OPTIONS (R03) - S23TKV8MS SUSPENSION, RAIL BEAM LH/RH - S23TKV8MS (C601667) Diagram

#

Description
Price

1

NUT-M6X1.0, FLG-NYLOC-OLIVE D

7547339

$1.49

1

NUT-M6X1.0, FLG-NYLOC-OLIVE D

7547339

$1.49

1

NUT-M6X1.0, FLG-NYLOC-OLIVE D

7547339

$1.49

1

NUT-M6X1.0, FLG-NYLOC-OLIVE D

7547339

$1.49

1

NUT-M6X1.0, FLG-NYLOC-OLIVE D

7547339

$1.49

2

WSHR-6.4X18.0X1.6 ZPB

7556064

$5.22

3

CAP, RAIL TIP

5452441

$16.99

4

SCR-TXTH-M6X1.0X30,8.8,ZPB

7520133

$3.19

5

SCR-10-24X1.25TFM PN TRX TRI-Y

7512025

$4.79

6

Washer, Flat

7555783

$3.99

6

Washer, Flat

7555783

$3.99

7

NUT-NYLOC 10-24 Y

7541925

$1.49

8

BUMPER, JOUNCE, FRONT

5522253

$8.89

9

SCR-HXFL- M6X1.0X70 10.9 ZOD

7519908

$4.79

9

SCR-HXFL- M6X1.0X70 10.9 ZOD

7519908

$4.79

10

WASHER, OFFSET

7556799

$3.19

10

WASHER, OFFSET

7556799

$3.19

11

ASM-WHEEL SPOKED 5.62

1590632

$38.39

11

BEARING-.7874X1.6535X.4724 NSK [1 PER WHEEL]

3515142

$19.99

11

RING-RETAINING [1 PER WHEEL]

7710444

$8.79

11

ASM-WHEEL SPOKED 5.62

1590632

$38.39

11

BEARING-.7874X1.6535X.4724 NSK [1 PER WHEEL]

3515142

$19.99

11

RING-RETAINING [1 PER WHEEL]

7710444

$8.79

12

SCR-HH-M6X1.0X25 8.8 ZPB

7517510

$4.79

12

SCR-HH-M6X1.0X25 8.8 ZPB

7517510

$4.79

13

SCR-M8X1.25X25 8.8TXTR ZOD P80

7518906

$3.19

14

BLOCK-WHEEL MOUNT

5633278

$29.99

14

BLOCK-WHEEL MOUNT

5633278

$29.99

15

SCR-TXTH-M8X1.25X20 8.8 ZB3 P3

7519997

$3.99

16

SCR-1/4-20X3/4,TR/TX/TAP-Y

7515199

$1.49

17

ASM-RAIL 129 CPL SVC LH BLK [COLOR OPTION][INCL. 19,20]

1544998-067

$609.99

17

ASM-RAIL 129 CPL SVC RH BLK [COLOR OPTION][INCL. 19,20]

1544999-067

$609.99

17

ASM-RAIL 129 CPL SVC LH RED [COLOR OPTION][INCL. 19,20]

1544998-293

$459.80

17

ASM-RAIL 129 CPL SVC RH RED [COLOR OPTION][INCL. 19,20]

1544999-293

$459.80

17

ASM-RAIL 129 CPL SVC LH ORG [COLOR OPTION][INCL. 19,20]

1544998-647

$609.99

17

ASM-RAIL 129 CPL SVC RH ORG [COLOR OPTION][INCL. 19,20]

1544999-647

$609.99

17

ASM-RAIL 129 CPL SVC LH VELBLU [COLOR OPTION][INCL. 19,20]

1544998-689

$459.80

17

ASM-RAIL 129 CPL SVC RH VELBLU [COLOR OPTION][INCL. 19,20]

1544999-689

$609.99

17

ASM-RAIL 129 CPL SVC LH LFTLM [COLOR OPTION][INCL. 19,20]

1544998-801

$609.99

17

ASM-RAIL 129 CPL SVC RH LFTLM [COLOR OPTION][INCL. 19,20]

1544999-801

$609.99

18

BLOCK-IDLER BOLT ADJ METRIC

5136570

$34.99

19

RIVET-FLAT HD-1/4 X .575

7621501

$2.39

20

SPACER-IDLER ADJ ALUM

5141837

$8.99

21

NUT-HEX-M10X1.5 8 ZOD

7547707

$4.99

22

SCR-HX-M10X1.5X100,8.8,ZOD

7520083

$12.79

23

BUMPER-FRT TORQ ARM, XTRA 12

5432166

$5.59

24

PLATE-RAIL REINF BLK ANODIZED

5143395

$194.99

25

SHAFT-SPRING ROLLER

5144612

$10.51

26

GUIDE, SPRING, SQUARE

5434334

$28.32

27

Pin, Clevis

7661123

$3.99

28

PIN, HITCH

7661644

$2.39

29

HI-FAX-129 LWT BLK

5522230-070

$56.65

30

SCR-M6X1.0X20 TR/TX/TAP ZOD

7518976

$3.19
