Polaris PATRIOT 9R INDY XCR 128 ALL OPTIONS (R02) - S25TKL9BS SUSPENSION, SHOCK, IFS - S25TKL9BS (601983) Diagram

#

Description
Price

-

SHOCK-IFS W/E 2" VEL HI/LO

7045773

$685.51

1

BODY-2.0 MIDMNT

1801085

$244.99

2

BRIDGE, 2", ANO BLUE

1800998

$314.99

3

SHAFT-.625X8.965L

1801086

$246.89

4

LOOP, SHAFT, .625THD

1801087

$97.13

5

RETAINER-SPRING CLIP, ANO BLUE

1800925

$39.99

6

ASM-PISTON, IFP 1.750

1801186

$64.99

7

ASM-SEAL HEAD 2.0

1801083

$141.65

8

BEARING, END

1800040

$94.99

9

SNAP RING, 1"ID

1800929

Unavailable

10

BODY-RESERVOIR 2.0" 3.75L

1800999

$119.99

11

O-RING, 2-324

1800184

$5.65

12

BUMPER, .62 IN SHAFT

1800462

$32.37

13

O-RING BODY LOOP

1800030

$2.02

14

O-RING, 2-226 1600018

1800863

$4.79

15

SPRING NUT- 2.0

1800936

$64.99

16

SCREW-SOC CAP M4X20

1801002

$3.99

17

ADJUSTER-HS-LS, V7

1801067

$459.99

18

RING-RETAINING 2.06OD

1801003

$20.22

19

END CAP, RESERVOIR, 2"

1801006

$114.99

20

RETAINING RING WIRE 0.0625 X 1.750ID

1800795

$7.27

21

NUT-FLEX-TOP LOCK 7/16

1801000

$7.99

22

ASM-PISTON

1801211

$217.84

23

DECAL NOT AVAILABLE

-------

Unavailable

24

WEAR BAND, SPRING

1800780

$64.99

25

SPRG-CMP .306X10.00 100#2" BLK

7045298-458

$48.40
