Honda PA50IIA (83) MOPED-30 MPH, BE, VIN# YC1AB090-DB300001 SWINGARM + MAIN STAND Diagram

#

Description
Price

1

HOUSING, AIR CLEANER ELEMENT

17204-148-000

Unavailable

2

ELEMENT, AIR CLEANER

17205-148-610

Unavailable

3

COVER, AIR CLEANER

17210-148-000

Unavailable

4

TUBE, AIR CLEANER IN. (NOT AVAILABLE)

17211-148-000

Unavailable

5

GASKET, ELEMENT CASE (NOT AVAILABLE)

17212-148-000

Unavailable

6

SPRING, AIR CLEANER SET (NOT AVAILABLE)

17213-148-000

Unavailable

7

TUBE, AIR CLEANER CONNECTING

17222-148-010

Unavailable

8

BAND A, AIR CLEANER IN. PIPE

17231-051-000

$4.63

8

BAND A, AIR CLEANER IN. PIPE This part replaces 17258-122-000.

17231-051-000

$4.63

9

GROMMET, FUEL PUMP CHAMBER (NOT AVAILABLE)

17656-579-010

Unavailable

10

COIL ASSY., IGNITION This part replaces 30500-GB7-671.

30500-GC6-000

Unavailable

11

COVER, IGNITION COIL (NOT AVAILABLE)

30510-148-010

Unavailable

12

CAP ASSY., NOISE SUPPRESSOR

30700-155-163

Unavailable

12

CAP ASSY., NOISE SUPPRESSOR This part replaces 30700-197-000.

30700-155-163

Unavailable

12

CAP ASSY., NOISE SUPPRESSOR This part replaces 30700-197-010.

30700-155-163

Unavailable

13

COVER, PEDAL CHAIN *NH1* (BLACK)

40510-148-010B

Unavailable

14

PIN, COVER SET

40514-148-000

Unavailable

15

SPRING, COVER SET

40515-148-000

Unavailable

16

COVER, BELT *NH1* (BLACK)

40520-148-720B

Unavailable

17

STAND, MAIN *NH1* (BLACK) (NOT AVAILABLE)

50500-148-670B

Unavailable

18

SHAFT, MAIN STAND

50501-148-000

Unavailable

19

SWINGARM, RR. *NH1* (BLACK)

52100-GB7-670B

Unavailable

20

COLLAR, RR. SWINGARM (NOT AVAILABLE)

52112-148-000

Unavailable

21

LABEL, MUFFLER CAUTION

87504-028-670

$2.92

22

LABEL, AIR CLEANER CAUTION

87508-120-000

$5.26

23

LABEL, COVER BELT (NOT AVAILABLE)

87516-148-671

Unavailable

24

PUMP ASSY. *NH1* (BLACK)

89400-148-000B

Unavailable

25

E-RING (8MM)

90300-099-000

Unavailable

26

WASHER, DISTANCE

90488-148-300

Unavailable

27

BOLT, HEX. (8X18) This part replaces 92000-08018-0A.

92101-08018-0A

$1.53

27

BOLT, HEX. (8X18)

92101-08018-0A

$1.53

28

BOLT, HEX. (8X30) This part replaces 92000-08030-0A.

92101-08030-0A

$1.49

28

BOLT, HEX. (8X30)

92101-08030-0A

$1.49

29

BOLT, HEX. (8X35) This part replaces 92000-08036-0A.

92101-08035-0A

$1.49

29

BOLT, HEX. (8X35)

92101-08035-0A

$1.49

29

BOLT, HEX. (8X35) This part replaces 92101-08036-0A.

92101-08035-0A

$1.49

30

BOLT, HEX. (8X40) This part replaces 92000-08040-0A.

92101-08040-0A

$1.80

30

BOLT, HEX. (8X40)

92101-08040-0A

$1.80

31

SCREW, PAN (5X16)

93500-05016-0A

$1.49

32

NUT, HEX. (8MM)

94001-08000-0S

$1.49

33

WASHER, PLAIN (8MM)

94101-08000

$1.49

34

WASHER, SPRING (5MM)

94111-05000

$1.49

35

WASHER, SPRING (8MM)

94111-08000

$1.49

36

SPRING D, MAIN STAND

95014-71402

$2.48
