Can-Am Outlander MAX 650 XT 4 X 4, 2006 09- Seat Diagram
#
1
Seat Assembly | Includes 1 to 6
708001649
Unavailable
2
Seat Base
708000403
Unavailable
3
Rubber Stopper
708000759
Unavailable
4
Seat Foam
708000404
Unavailable
5
Seat Cover
708000538
Unavailable
6
SEAT CORNER, BLACK - Call your local BRP dealership
708000127
Unavailable
7
Bumper Rubber
708000760
Unavailable
8
Latch, Black
708000144
Unavailable
9
Hex. Screw M6 X 110
230061044
Unavailable
10
Spring
708000369
Unavailable
11
Push Nut
732610072
Unavailable
12
REINFORCEMENT SEAT - Call your local BRP dealership
708000817
Unavailable
13
Hex. Flange Screw M6 X 12
210261250
Unavailable
14
REFLECTING SHEET - Call your local BRP dealership
708000956
Unavailable
15
REFLECTING SHEET - Call your local BRP dealership
708000470
Unavailable
16
Emission Label
704901261
Unavailable
17
HEAT SHIELD - Call your local BRP dealership
708000957
Unavailable
18
Rear Seat Ass'y | Includes 16 to 20
708000805
Unavailable
19
Seat Base
708000455
Unavailable
20
Panel Nut M6 X 1.0
250100198
Unavailable
21
Seat Foam
708000456
Unavailable
22
Seat Cover
708000457
Unavailable
23
LATCH HANDLE - Call your local BRP dealership
708000822
Unavailable
24
Hex. Flange Screw M6 X 20
207662044
Unavailable
25
Bumper Rubber
708000760
Unavailable
26
Backrest Ass'y
708000809
Unavailable
27
Backrest Foam
708000464
Unavailable
28
Backrest Cover
708000465
Unavailable
29
Hex. Flange Screw M6 X 20
207662044
Unavailable
30
Hex. Flange Elastic Nut M6 x 1.0
233261414
Unavailable
31
LH BACKREST STEM - Call your local BRP dealership
708000439
Unavailable
32
RH BACKREST STEM - Call your local BRP dealership
708000443
Unavailable
33
REAR PLATE - Call your local BRP dealership
708000855
Unavailable
34
FRONT PLATE - Call your local BRP dealership
708000446
Unavailable
35
Hex. Flange Screw M8 X 20
207682044
Unavailable
36
Hex. Flange Screw M8 X 25
207682544
Unavailable
37
Hex. Flange Elastic Nut M8
233281414
Unavailable
38
Flat Washer 8 mm
234082410
Unavailable
39
LATCH - Call your local BRP dealership
708000448
Unavailable
40
Hex. Screw M6 X 55
207065544
Unavailable
41
Push Nut
732610072
Unavailable
42
Spring
708000369
Unavailable
43
ROD GUIDE - Call your local BRP dealership
708000461
Unavailable
44
Hex. Jam Nut M8
232180600
Unavailable
45
Hex. Screw M8 X 20
207182044
Unavailable
46
INNER BUSHING - Call your local BRP dealership
708000462
Unavailable
47
HEX. CAP SCREW M6 X 50 - Call your local BRP dealership
207065044
Unavailable
48
Hex. Flange Elastic Nut M6 x 1.0
233261414
Unavailable
49
BOX ASS'Y - Call your local BRP dealership | Includes 41 to 47
708200119
Unavailable
50
LATCH - Call your local BRP dealership
708200066
Unavailable
51
Hex. Screw M6 X 55
207065544
Unavailable
52
Push Nut
732610072
Unavailable
53
Spring
708000369
Unavailable
54
BELT - Call your local BRP dealership
510004495
Unavailable
55
Cover Latch
708200120
Unavailable
