- Outlander 800REFI Xmr, 2012
08- Rear Suspension
Can-Am Outlander 800REFI Xmr, 2012 08- Rear Suspension Diagram
#
1
COMPRESSOR ASS'Y - Call your local BRP dealership | Includes 1a to 1b
706000745
Unavailable
2
Compressor Bracket
715900072
Unavailable
3
Hex. Flange Screw M10 X 25
207602544
Unavailable
4
Hex. Flange Elastic Nut M10
233201414
Unavailable
5
Hex. Flange Screw M8 X 16, Scotch Grip
207581644
Unavailable
6
T-FITTING - Call your local BRP dealership
706000935
Unavailable
7
Hose 4.32Mm 3000Mm Long
219704415
Unavailable
8
Hose 4.32Mm 3000Mm Long
219704415
Unavailable
9
HOSE - Call your local BRP dealership
415129495
Unavailable
10
Clamp Oetiker
293650207
Unavailable
11
Front Compressor Support
706000941
Unavailable
12
AIR MANIFOLD ASS'Y - Call your local BRP dealership | Includes 12 to 17
706001095
Unavailable
13
Connector
706000869
Unavailable
14
Check Valve
706000860
Unavailable
15
Housing
710001927
Unavailable
16
LOW TEMPERATURE TUBING 1/2? 3000MM LONG - Call your local BRP dealership
219704427
Unavailable
17
Elbow 90°
706000872
Unavailable
18
Hex. Flange Screw M6 X 16, Scotch Grip
207561644
Unavailable
19
Pneumatic Hose Ass'y | Includes 19 to 21
706001034
Unavailable
20
Hose 4.32Mm 3000Mm Long
219704415
Unavailable
21
Tubing 6 Mm 3000Mm Long
219704425
Unavailable
22
Flat Washer 14 mm
234071410
Unavailable
23
O-RING - Call your local BRP dealership
293300146
Unavailable
24
FILTER - Call your local BRP dealership
706000832
Unavailable
25
Hose Ass'y | Includes 25 to 28
706001083
Unavailable
26
Polyurethane Hose 10000Mm Long
219704410
Unavailable
27
Check Valve
513033469
Unavailable
28
Polyurethane Hose 10000Mm Long
219704410
Unavailable
29
ELBOW 90 - Call your local BRP dealership
706000796
Unavailable
30
BRACKET ASS'Y - Call your local BRP dealership | Includes 34 to 36
706000853
Unavailable
31
Hose 4.32Mm 3000Mm Long
219704415
Unavailable
32
O-Ring
414811400
Unavailable
33
Mount Dart
293730040
Unavailable
34
Tie Wrap 142 mm
293750002
Unavailable
35
Pop Rivet 3/16"
390406500
Unavailable
36
Hex. Flange Elastic Nut M5
233251414
Unavailable
37
FITTING ASS'Y - Call your local BRP dealership
706000939
Unavailable
38
Check Valve
706000940
Unavailable
39
T-FITTING - Call your local BRP dealership
706000795
Unavailable
40
ELBOW 90 - Call your local BRP dealership
706000793
Unavailable
41
Auxiliary Hose
706000808
Unavailable
42
Tie Wrap 368 mm
293750008
Unavailable
43
MODULE KIT - Call your local BRP dealership | Includes 43 to 44
703500895
Unavailable
44
Tubing 6 Mm 3000Mm Long
219704425
Unavailable
45
Clamp Oetiker
293650207
Unavailable
46
Air Suspension Sensor
710001825
Unavailable
47
HEX. FLANGED SCREW M4 X 10 - Call your local BRP dealership
210241080
Unavailable
48
Hose 4.32Mm 3000Mm Long
219704415
Unavailable
