08- Drive System, Rear
Can-Am Outlander 800REFI Xmr, 2012 08- Drive System, Rear Diagram
#
1
Rear Propeller Shaft Kit | Includes 1 to 9
703500803
Unavailable
2
Fixe Yoke
715900101
Unavailable
3
Universal Joint
715900326
Unavailable
4
SLIDING JOINT - Call your local BRP dealership
705501072
Unavailable
5
Rubber Boot Kit | 4X4 / Includes 3 to 5
703500255
Unavailable
6
Oetiker Gear Clamp 44.0MM | 4X4
293650138
Unavailable
7
Not Available As Spare Part - Friction Washer
Unavailable
8
DISC JOINT - Call your local BRP dealership
705500526
Unavailable
9
GREASE FITTING - Call your local BRP dealership
705500841
Unavailable
10
Protector
705501123
Unavailable
11
Wear Ring | 4X4
705400036
Unavailable
12
Differential Kit | Includes 10 to 29
703501033
Unavailable
13
Oil Seal | 4X4
705401481
Unavailable
14
Nut
705502059
Unavailable
15
Ball Bearing | 4X4
705500260
Unavailable
16
Pinion Gear Shim .022"
705500075
Unavailable
16
Pinion Gear Shim 1.67 mm
705502061
Unavailable
16
Pinion Gear Shim
705501162
Unavailable
17
Differential Shim 0.02 mm
705502060
Unavailable
18
Ens Engrenage 10/36D *Gear-10/36 Too Kit
703500873
Unavailable
19
Needle Bearing
705501408
Unavailable
20
Ball Bearing
705502737
Unavailable
21
Ball Bearing
705502738
Unavailable
22
Ens Engrenage 10/36D *Gear-10/36 Too Kit
703500873
Unavailable
23
Screw | 4X4
705401601
Unavailable
24
REAR DIFFERENTIAL COVER - Call your local BRP dealership
705501507
Unavailable
25
Seal | 4X4
705500265
Unavailable
26
PINION REAR COVER - Call your local BRP dealership
705501395
Unavailable
27
VENT VALVE - Call your local BRP dealership | 4X4
705500893
Unavailable
28
Drain Plug | 4X4
705500894
Unavailable
30
O-Ring | 4X4
705500267
Unavailable
31
Oil Seal
705501996
Unavailable
32
Fill Level Plug | 4X4
705500504
Unavailable
33
Copper Washer | 4X4
705500506
Unavailable
34
LH WHEEL HUB ASSEMBLY - Call your local BRP dealership | 4X4 / Includes 65 to 66
705501713
Unavailable
35
Wheel Stud M10 X 1.25 | 2X4
250300055
Unavailable
36
Protector Kit | Includes 38 to 39
703500722
Unavailable
38
Hex. Flange Screw M6 X 25
207662544
Unavailable
39
Hex. Flange Elastic Nut M6 x 1.0
233261414
Unavailable
40
Flat Washer
250200082
Unavailable
41
Hex Flange Screw M12 X 16
250001039
Unavailable
42
Flat Washer M12
250200102
Unavailable
43
Polyurethane Hose 10000Mm Long
219704410
Unavailable
45
Hex Flange Screw M12 X 16
250001039
Unavailable
47
Wheel Cap
705401318
Unavailable
48
TIRE_30X9R14 - Call your local BRP dealership
705400962
Unavailable
49
Rim
705400877
Unavailable
50
Rim Valve With Cap
705400193
Unavailable
51
1/2 Oz Weight
219704465
Unavailable
54
Valve Cap
293000110
Unavailable
56
Black, Wheel Nut M10 X 1.25
250100184
Unavailable
57
Flat Washer M12
250200102
Unavailable
58
Hex. Flange Castellated Nut M18
232291413
Unavailable
59
Cotter Pin
250400036
Unavailable
61
LH Rear - Premium CV Axle | Includes 58a to 63a
705501485
Unavailable
62
CV JOINT - Call your local BRP dealership
705500980
Unavailable
63
Boot Kit
705500870
Unavailable
63a
Oetiker Clamp (27,5mm)
293650203
Unavailable
63b
OETIKER CLAMP - Call your local BRP dealership
293650204
Unavailable
64
CIRCLIP - Call your local BRP dealership
705500845
Unavailable
65
RH Rear - Premium CV Axle | Includes 64a to 69a
705501486
Unavailable
66
CV JOINT - Call your local BRP dealership
705500980
Unavailable
67
Boot Kit
705500870
Unavailable
67a
Oetiker Clamp (27,5mm)
293650203
Unavailable
67b
OETIKER CLAMP - Call your local BRP dealership
293650204
Unavailable
68
CIRCLIP - Call your local BRP dealership
705500845
Unavailable
70
Hex. Flange Screw M10 X 135
250001041
Unavailable
71
Hex. Flange Elastic Nut M10
233201434
Unavailable
72
Ball Bearing
293350150
Unavailable
73
Wear Ring
705501124
Unavailable
74
Wear Sleeve | 4X4
705501121
Unavailable
75
Circlip
293370019
Unavailable
76
Conical Spring Washer M18
250200171
Unavailable
