Honda NT1100PYB (25) MOTORCYCLE, JPN, VIN# JH2SC908-SK000001 TO JH2SC908-SK099999 SIDE BOX Diagram

#

Description
Price

1

RUBBER, MUFFLER MOUNTING

18421-MN5-000

$5.12

2

COLLAR, MUFFLER MOUNTING

18422-MN5-000

$9.05

3

RUBBER, RADIATOR MOUNTING

19051-KA4-700

$3.25

4

BOX ASSY., R. SIDE

77520-MLF-Y10

$494.09

5

FASTENER SET, R.

77525-MV8-750

$21.87

6

FASTENER SET, L.

77526-MV8-750

$21.87

7

BOX ASSY., L. SIDE

77530-MLF-Y10

$494.09

8

RUBBER, SIDE BOX

77601-MCP-900

$20.25

9

SPACER, FASTENER

77709-MV8-750

$2.26

10

RUBBER, SUB-CARRIER

81310-HA0-680

$3.77

11

RUBBER, SHOCK POOL

81404-292-750

$8.92

12

STAY, R. SIDE BOX

84150-MLF-Y10

$854.92

13

PIPE

84161-MJL-Y10

$120.58

14

STAY, L. SIDE BOX

84250-MLF-Y00

$769.11

15

BOLT, FLANGE (6X28)

90021-GHB-690

$2.23

16

BOLT, FLANGE (5X50)

90036-GHB-760

$3.26

17

BOLT, FLANGE (8X55)

90036-GHB-770

$2.95

18

BOLT, SPECIAL (6X22)

90085-KFB-000

$3.42

19

BOLT, FLANGE (8X110)

90103-MLF-Y00

$4.57

20

NUT, FLANGE CAP (8MM)

90301-MKS-E20

$3.20

21

NUT, CAP (6MM)

90308-MT8-000

$2.70

22

COLLAR (6.2X13)

90501-MA3-720

$4.78

23

SCREW, PAN (3X10)

93500-03010-0A

$1.49

24

WASHER, PLAIN (3MM)

94103-03000

$1.49

25

WASHER, PLAIN (8MM)

94103-08700

$1.49

26

WASHER, SPRING (3MM)

94111-03000

$1.49

27

RUBBER C, STAND STOPPER

95011-63000

$3.90
