Honda NSS250AAC (03) MOTOR SCOOTER, JPN, VIN# JH2MF064-3K100001 SEAT@REAR SPOILER Diagram

#

Description
Price

1

SPRING, GOVERNOR

16561-ZE7-020

$3.35

2

SWITCH ASSY., DOOR

35400-SL4-013

$26.36

3

COVER, DOOR SWITCH

35401-SL4-003

Unavailable

4

SCREW, FLANGE (4X12)

35409-692-013

$4.61

5

SPRING

50513-GBL-000

$3.33

6

SPRING, LOCK KEY SETTING

75581-GN8-920

$4.78

7

HINGE ASSY., SEAT

77110-KPB-010

Unavailable

8

RUBBER, SEAL

77114-KPB-000

Unavailable

9

SEAT, DOUBLE

77200-KPB-000

Unavailable

10

BACKREST ASSY.

77210-KPB-000

Unavailable

11

CATCH, RR. SEAT

77220-KPB-000

Unavailable

12

BAND, RUBBER

77227-KPB-000

$1.49

13

CATCH, SEAT

77230-KPB-000

Unavailable

14

GUIDE, SEAT CATCH

77238-KPB-000

$20.98

15

KEY, SEAT LOCK

77239-196-017

$42.15

16

CABLE A, SEAT OPEN

77240-KPB-000

Unavailable

17

CABLE B, SEAT OPEN

77241-KPB-000

$10.82

18

STAY, SEAT LOCK CABLE

77244-KPB-000

Unavailable

19

SPOILER, RR. *Y106* (CLIPPER YELLOW)

77310-KPB-000ZN

Unavailable

20

COVER, RR. SPOILER

77315-KPB-000

$11.00

21

BOLT, SPECIAL FLANGE (8X35)

90107-ME7-000

$5.16

22

SCREW, PAN (6X16)

90113-KPB-000

$2.49

23

BOLT, GROUND (6X16)

90149-SE0-003

$7.20

24

SCREW, TAPPING (5X12)

93904-35280

$1.49

25

NUT, FLANGE (6MM)

94050-06070

$1.49

26

BOLT, FLANGE (6X16)

95701-06016-08

$1.49

27

BOLT, FLANGE (8X20)

95701-08020-00

$1.78
