Honda NSR50RA (04) MINI 50, JPN, VIN# RS50-1100516 TO RS50-1101643 REAR WHEEL Diagram

SPROCKET, FINAL DRIVEN (42T)

41200-GT4-690

$54.61

COLLAR, RR. WHEEL SIDE

42311-GS9-000

Unavailable

COLLAR, RR. AXLE

42311-GT4-000

Unavailable

COLLAR, RR. WHEEL DISTANCE

42620-GS3-000

$14.55

WHEEL SUB-ASSY., RR.

42650-NLA-000

$795.74

TIRE ASSY., RR. (NOT AVAILABLE)

42710-NLA-000

Unavailable

VALVE, RIM (DUNLOP)

42753-ML7-004

$11.44

DISK, RR. BRAKE

43121-GT4-710

Unavailable

BOLT, FR. DISK (8X24)

90105-KR3-000

$5.64

BOLT, RR. SWINGARM PIVOT

90121-KE2-980

$40.10

BOLT, STUD (10X31)

90125-GE2-740

$5.78

NUT, U (10MM)

90304-GE8-003

$3.42

NUT, FLANGE (12MM)

90306-KF0-003

Unavailable

WASHER, PLAIN (12MM)

90440-GT4-970

$2.38

OIL SEAL (26X37X6) (ARAI)

90753-051-003

$7.13

OIL SEAL (26X37X6) This part replaces 90753-051-005.

90753-051-003

$7.13

DUST SEAL (20X32X5) (NOK) This part replaces 90754-GC8-003.

90754-GC8-005

$4.70

DUST SEAL (20X32X5) (NOK)

90754-GC8-005

$4.70

BEARING, RADIAL BALL (6201UU)

96150-62010-10

$11.49

BEARING, RADIAL BALL (6301UU)

96150-63010-10

$9.32
