Ski-Doo MXZ 120, 2026 Engine - Air Cleaner Diagram

#

Description

Price

1

Self tapping Screw

3020-094

$4.36

2

Filter Cover

3020-055

$33.99

3

Air Cleaner Filter

3020-056

$34.99

4

Retaining Plate

3020-057

$32.99

5

Self Tapping Screw

1623-661

$2.89

6

M8X1.25X25 CAP Screw

8408-825

$1.37

7

Air Cleaner Case

3020-054

$99.99

8

Hex Lock Nut M8X1.25

8427-802

$0.62

9

Intake Insulator

3020-058

$23.99

10

Intake Tube

2670-110

$25.99

11

Hex Flange Elastic Nut M6X1.0

8427-602

$0.25

12

Carburator To Intake Gasket

3020-053

$5.49

13

Intake Gasket

3020-021

$2.99

14

Carburator Insulator

3020-022

$14.49
