Ski-Doo North America - MXZ 120, 2025 Rear Suspension Arm Diagram

#

Description
Price

0

Complete Skid Frame Ass'y

3704-993

Unavailable

1

Rail

4604-548

$99.99

2

Black, Wearstrip

4604-552

$10.32

3

Machine Screw

2623-315

$0.87

4

Slide Rail End Cap

4604-093

$7.89

5

Machine Screw M6X1.0

8476-630

$1.19

6

Hex Flange Elastic Nut M6X1.0

8427-602

$0.25

7

Axle Cross Brace

4604-276

$26.99

8

Strap Limiter

1604-708

$29.99

9

Cap Screw 1/4-20 X1.125

8002-043

$0.76

10

Flat Washer 1/4 X .734 X .063

8050-222

$0.72

11

Elastic Stop Nut 1/4-20

8047-366

$0.49

12

Shock Pad

0104-631

$7.89

13

Nut Press On (Pushnut) - 1/8 Stud

0423-090

$0.48

14

Rivet 1/8 X 1.50

0123-767

$1.09

15

Cap Screw 5/16-18

1623-566

$1.91

16

Flat Washer 5/16 X .875 X .063

8050-252

$0.76

17

Track Adjuster

3604-647

$4.19

18

Cap Screw M8 X 1.25 X 100

1623-682

$2.01

19

Elastic Locking NutM6X1.0

8422-802

$0.49

20

Cap Screw 3/8-16X1

1623-427

$2.29

21

Flat Washer 1.00X.390X.164

0623-664

$1.39

22

Idler Wheel

4604-355

$35.99

23

Bearing

3604-033

$22.49

24

Retaining Ring

0623-946

$2.44

25

Rear Wheel Spacer 17.87

4604-484

$5.89

26

Flat Washer

0623-921

$1.89

27

Rear Wheel Spacer

3604-934

$9.19

28

Rear Axle

3604-542

$45.99

29

Rear Wheel Spacer

4604-483

$6.59

30

Front Arm

3704-655

$109.99

31

Black, RH Block Spring Adjuster

1604-204

$22.99

31

Black, LH Block Spring Adjuster

1604-205

$22.99

32

Retaining Ring

0623-138

$0.72

33

Bearing

0603-083

$10.11

34

Axle Lower Arm

4604-482

$16.99

35

Axle

3604-605

$40.99

36

Spacer

3602-236

$4.09

37

RH Suspension Spring

3704-172

$74.99

37

LH Suspension Spring

3704-173

$74.99

38

Cap Screw 5/16-18

8020-131

$1.89

39

Spacer

1604-565

$5.49

40

Idler Wheel

4604-413

$24.49

41

Bearing

4604-414

$25.99

42

Retaining Ring

2623-269

$0.72

43

Axle

3604-605

$40.99

44

Spacer

1604-564

$20.99

45

Track Ass'y

3602-047

$499.99

46

Guide Clip

2602-386

$4.19
