Ski-Doo MXZ 120, 2025 Engine and Components Diagram

#

Description
Price

1

Engine (120)

0662-560

$1,179.99

2

Throttle Lever Bracket

0608-807

$20.74

3

Spacer M6

2670-119

$14.49

4

Throttle Lever Return Spring

2670-134

$8.49

5

Throttle Cable Lever

2670-194

$20.74

6

Flat Washer 1/4 X .734 X .063

8050-222

$0.71

7

Elastic Stop Nut 1/4-20

8047-366

$0.50

8

Governor Arm Spring

2670-193

$16.89

9

Screw M8 X 1.25 X 16

8408-816

$0.71

10

Screw, #10-32 X 1.50

1623-901

$1.23

11

Throttle Stop Adjuster Spring

2670-133

$12.19

12

Breather Hose 7.5"

0610-821

$21.99

13

Governor Arm Return Spring

2670-127

$16.89

14

Resonator Retaining Bracket

4606-770

$4.98

15

Wire Clamp 76.14MM LG W/6.25 HOL

1623-984

$7.29

16

Cap Screw 5/16-18

8020-134

$1.69

17

Elastic Stop Nut 1/4-20

8047-426

$0.71

18

Blanking Plug 1.25"

2623-277

$2.29

19

Screw 5/16-24 X .75

1623-550

$4.09

20

Flat Washer

8050-247

$0.71

21

Lock Washer 1/4

8053-212

$0.20
