Can-Am Defender - HD9 - DPS CAB - 8UTE - Compass Green - 62" Width - CALI, 2026 Enclosure Cab - Air Conditioning System Diagram

Description

Price

1010

LH Manifold Ass'y | Includes 1010 to 1010a

705800649

$18.43

1010a

LH Manifold

705800428

$18.43

1012

Tuflok Plastic Rivet

293150230

$1.21

1015

RH Manifold Ass'y | Includes 1015 to 1015a

705800650

$18.43

1015a

RH Manifold Ass'y | Includes 1015 to 1015a

705800650

$18.43

1030a

Grille Scoop

705800436

$23.05

1030b

Duct Ventilation Kit

705800706

$10.00

1030c

Duct Ventilation Kit

705800706

$10.00

1030d

Duct Ventilation Kit

705800842

$67.66

1030d4

Anchorage Tie Wrap

293750094

$0.91

1030f

Ventilation Duct Kit

705800707

$71.51

1030f3

Anchorage Tie Wrap

293750094

$0.91

1035

Adaptor

705800690

$27.66

1040a

Grille Scoop

705800436

$23.05

1070

Intake Duct

705800377

$27.66

1075

Lower Intake Fitting

705800437

$18.43

1080

Upper Intake Fitting

705800438

$55.35

1085

Upper Intake Duct

705800439

$32.28

1090

Air Filter

705800395

$32.28

1092

Torx Screw K50 X 16

250000720

$1.39

1095

Norma Gear Clamp

293650118

$9.74

1096

Overmolded Grommet

293720130

$4.38

1097

Flat Washer

250200040

$1.82

1098

Torx Screw K50 X 16

250000720

$1.39

4200

Central Adapter

705800501

$27.66

4205

Front Ventilation Grille

705800425

$11.18

4210

Torx-Truss Pt K40 X 16

250000759

$1.74

4240

Side Grille Support

705800426

$4.95

4250

Central Grille Support Kit

715011233

$32.28

4255

Tuflok Plastic Rivet

293150230

$1.21

4260

LH Lower Grille Support

705801099

$23.05

4270

Stainless Steel Flat Washer

234062670

$1.74

4280

Torx Screw M6 X 20

250000722

$1.34
