Sea-doo CRUISE 18 - 230 - 45RA - Blue - Trailer Paint - CAT2B, 2024 Electric - Main Harness - 278004245 Diagram

#

Description
Price

1000

Main Wiring Harness

278004245

Unavailable

1000h

Positive Cable

278003888

Unavailable

BLWR

Amphenol Female Connector 2 Cavities

515178579

$10.14

BLWR

Amphenol Lock Connector

515178580

$3.68

BLWR

Terminal

278003855

$12.60

BP

Positive Cable

278004257

Unavailable

COM

Female Housing 6 Circuits

710002706

$16.22

COM

Lock

710002705

$3.61

COM

Terminal

278003855

$12.60

COM

Female Terminal

710005438

$4.00

COM

Female Terminal

710005439

$4.28

DF

Female Housing 6 Circuits

710002706

$16.22

DF

Lock

710002705

$3.61

DF

Plug

710005437

$3.08

DF

Female Terminal

710005439

$4.28

DF

Female Terminal

710005438

$4.00

ECMB

Cover, 48 positions

710001591

$10.05

ECMB

Female Terminal Housing, 48 Circuits

710001588

$39.62

ECMB

Plug

710001593

$2.12

ECMB

Plug

710001592

$2.12

ECMB

Female Terminal

710001590

$1.69

ECMB

Female Terminal

710001727

$2.55

ECMB

Female Terminal

710001589

$1.79

EGTS

Housing

710001136

$10.47

EGTS

Seal

415128501

$1.51

EGTS

Female Terminal

710001137

$3.73

FB

Fuse Box Cover

278003724

Unavailable

FB

Little Fuse, 5 Amperes

710000742

$7.24

FB

Little Fuse, 5 Amperes

710000742

$7.24

FB

Little Fuse, 15 Ampere

710000745

$6.77

FB

Little Fuse, 15 Ampere

710000745

$6.77

FB

Little Fuse, 15 Ampere

710000745

$6.77

FB

Little Fuse, 15 Ampere

710000745

$6.77

FB

Little Fuse, 15 Ampere

710000745

$6.77

FB

Little Fuse, 15 Ampere

710000745

$6.77

FB

Little Fuse, 3 AMP

710001008

$2.98

FB

Little Fuse, 3 AMP

710001008

$2.98

FB

Little Fuse, 3 AMP

710001008

$2.98

FB

Little Fuse, 3 AMP

710001008

$2.98

FB

Little Fuse, 30 Amperes

710000747

$6.77

FB

Little Fuse, 30 Amperes

710000747

$6.77

FB

Little Fuse, 30 Amperes

710000747

$6.77

FB

Little Fuse, 30 Amperes

710000747

$6.77

FB

Little Fuse, 30 Amperes

710000747

$6.77

FB

Fuse Base Ass'y

278003448

$26.62

FB

Seal Plug

278002880

$5.43

FB

Relay 30 Amp

278003828

$9.78

FB

Wire Seal

278000218

$3.48

FB

Wire Seal

710000048

$5.10

FB

Wire Seal

278001065

$6.03

FB

Female Terminal

515177177

$5.11

FB

Female Terminal

710000918

$5.10

FB2

50A Fuse

710007318

$18.82

FB2

Fuse Holder Support

710007204

$8.26

FB2

Elastic Stop Nut M5

232551414

$0.72

FB2

Terminal Ring

515177799

$7.24

FB2

Phillips Screw M5 X 12 | Not Shown

208651200

$2.09

FLIC

Insulated Sheath

278001007

$3.22

FLIC

Wire Seal

278000216

$2.55

FLIC

Female Terminal

710000421

$5.46

FP

Male Housing, 4 Circuits

278002185

$5.86

FP

Lock

710001222

$1.68

FP

Wire Seal

278002186

$4.51

FP

Female Terminal

278002187

$5.04

GND1

Open Barrel

278000992

$1.79

GND2 (ST)

Terminal

710000913

$5.46

GND3

Open Barrel Terminal

278001392

$4.12

GND4

Open Barrel Terminal

278001392

$4.12

GND5

Open Barrel Terminal

278001392

$4.12

GND6 (ST)

Open Barrel Terminal

278001392

$4.12

GTWY

Female Terminal Housing 6 Circuits

278002299

$8.85

GTWY

Female Terminal

278001114

$2.55

GTWY

Female Terminal

710001119

$4.32

HIC

Female Housing, 4 circuits

278003535

$25.35

HIC

Female Terminal

515178014

$1.92

HIC

Female Terminal

515178018

$0.78

HIC1

Female Housing 20 Circuits

278002858

$20.12

HIC1

Sealing Cap

278002860

$1.42

HIC1

Female Terminal

515178014

$1.92

HIC1

Female Terminal

515178018

$0.78

HIC2

Connector Molex Mx150 16 Pos

710005979

Unavailable

HIC2

Sealing Cap

278002860

$1.42

HIC2

Female Terminal

515178014

$1.92

HIC2

Female Terminal

515178018

$0.78

HIC3

Housing

710001157

$17.66

HIC3

Lock

710001323

$6.15

HIC3

Wire Seal

710001159

$6.45

HIC3

Female Terminal

710001160

$5.14

IBR

Female Housing ,16 Circuits

278003484

$14.27

IBR

Seal Plug

278002880

$5.43

IBR

Sealing Cap

278002860

$1.42

IBR

Seal

278003046

$0.74

IBR

Female Terminal

278003045

$2.34

IBR

Female Terminal

515178018

$0.78

NAVLTS

Clip

278003549

$2.75

NAVLTS

Housing 6 Circuits

278003866

$11.06

NAVLTS

Male Terminal

515178293

$14.02

O2 POST

Housing

710002466

$2.98

O2 POST

Lock

710002469

$1.98

O2 POST

Seal

278001482

$2.55

O2 POST

Terminal

710000736

$5.35

O2 PRE

Housing

710002466

$2.98

O2 PRE

Lock

710002469

$1.98

O2 PRE

Seal

278001482

$2.55

O2 PRE

Terminal

710000736

$5.35

OBDM

Housing

515177151

$4.68

OBDM

Housing

278003746

$10.98

OBDM

Cap

710001225

$7.27

OBDM

Seal Wire

710001332

$2.72

OBDM

Seal

710001233

$2.55

OBDM

Terminal

710001228

$2.72

OBDM

Terminal

710001229

$3.02

PU

Male Connector, 2 Circuits

278000220

$11.02

PU

Wire Seal

278000218

$3.48

PU

Female Terminal

409007300

$0.36

PU2

Male Connector, 2 Circuits

278000220

$11.02

PU2

Female Housing, 2 Circuits

278000217

$7.59

PU2

Wire Seal

278000216

$2.55

PU2

Wire Seal

278000218

$3.48

PU2

Female Terminal

409007300

$0.36

RE2

Female Housing, 3 Circuits

710000879

$21.42

RE2

Seal

710001932

$3.15

RE2

Seal

278003685

$13.82

RE2

Terminal

710001934

$4.51

STS

Female Housing, 2 Circuits

515177192

$6.32

STS

Lock

710001152

$3.48

STS

Seal Wire

710001153

$1.79

STS

Terminal

710000925

$2.55
