Sea-doo BASE Compact - 130 - 41TA - Can-Am Red - Trailer paint - CAT-NA - 2026 GUARD RAILS - Front Diagram

#

Description
Price

4000

LH Front Profiled Tube

281300714

Unavailable

4005

Plastite Torx Screw M6.81X30 | Not Shown

250000879

$2.00

4010

LH Front Hand Rail

281300350

Unavailable

4020

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

4030

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

4040

LH Lower Profile Tube

281300349

Unavailable

4045

Cone Torx Truss Screw HD.M6 X 51

250001185

$3.66

4050

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

4055

Balustrade Anchor

281300811

Unavailable

4095

Tuflok Plastic Rivet

293150230

$1.39

4098

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

4100

LH Front Trim Support

281300294

Unavailable

4120

LH Upper Lateral Tube

281300284

Unavailable

4130

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

4140

Lava Gray, LH Upper Rail Support

281300257

Unavailable

4150

Lava Gray, RH Upper Rail Support

281300256

Unavailable

4160

Screw-Torx Truss Cone HD.M6X50 | Includes 270 to 270

250000827

$3.82

4165

Stainless Flat Washer M6

234061600

$0.28

4170

Elastic Stop Nut M6, Brass

232561200

$4.03

4180

LH Lower Cap

281300311

Unavailable

4500

RLH Front Profiled Tube

281300715

Unavailable

4505

Plastite Torx Screw M6.81X30 | Not Shown

250000879

$2.00

4510

RH Front Hand Rail

281300355

Unavailable

4520

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

4530

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

4540

Rear Lower Profiled Tube

281300356

Unavailable

4545

Cone Torx Truss Screw HD.M6 X 51

250001185

$3.66

4550

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

4555

Balustrade Anchor

281300811

Unavailable

4595

Tuflok Plastic Rivet

293150230

$1.39

4598

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

4600

RH Front Trim Support

281300297

Unavailable

4620

RH Upper Laterak Tube

281300482

Unavailable

4630

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

4640

Lava Gray, LH Upper Rail Support

281300257

Unavailable

4650

Lava Gray, RH Upper Rail Support

281300256

Unavailable

4660

Screw-Torx Truss Cone HD.M6X50 | Includes 270 to 270

250000827

$3.82

4665

Stainless Flat Washer M6

234061600

$0.28

4670

Elastic Stop Nut M6, Brass

232561200

$4.03

4680

RH Lower Cap

281300312

Unavailable

5000

Front Door Service Kit

295101538

Unavailable

5005

Hex Screw M6 X 20

250000965

$2.00

5005a

Not Available As Spare Parts

XXX

Unavailable

5010

Front Balustrade Ass'y

281300844

Unavailable

5015

Balustrade Anchor

281300811

Unavailable

5030

RH Front Trim Support

281300297

Unavailable

5040

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

5045

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

5050

LH Front Trim Support

281300294

Unavailable

5060

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

5065

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

5080

Tuflok Plastic Rivet

293150230

$1.39

5085

Cone Torx Truss Screw HD.M6 X 15

250001147

$3.45

5090

Upper Front Tube

281300281

Unavailable

5100

Venturi Bushing

293900007

$4.25

5120

LH Upper Cap

281300309

Unavailable

5130

RH Upper Cap

281300310

Unavailable
