Description

Price

11010

FILTER-ASSY-AIR

11010-1820

$309.66

11013

ELEMENT-AIR FILTER

11013-0812

$55.05

14037

SCREEN,RAM DUCT

14037-0830

$13.09

14073

DUCT,RAM AIR

14073-0952

$7.43

14073A

DUCT-ASSY,RAM

14073-1920

$78.77

39156

PAD

39156-2540

$22.36

39156A

PAD

39156-2541

$10.07

39156B

PAD

39156-2542

$7.87

49116

VALVE-ASSY,AIR CUT

49116-0047

$82.04

92015

NUT,WELL,5MM

92015-1757

$7.29

92037

CLAMP,HOSE CLIP

92037-1460

$10.81

92066

PLUG,DRAIN

92066-0782

$10.34

92071

GROMMET

92071-0026

$3.87

92093

SEAL,ELEMENT

92093-0707

$4.55

92093A

SEAL

92093-0739

$14.80

92093B

SEAL,RAM DUCT

92093-0740

$20.48

92152

COLLAR,6.5X10.5X13.1

92152-0547

$5.65

92153

BOLT,UPSET-WP,6X16

92153-1587

$1.78

92154

BOLT,SOCKET,5X16

92154-1701

$1.19

92160

DAMPER

92160-1162

$5.00

92161

DAMPER

92161-2440

$21.90

92171

CLAMP

92171-0677

$12.29

92172

SCREW,TAPPING,5X20

92172-0483

Unavailable

92172A

SCREW,5X25

92172-0891

$1.94

92173

CLAMP,20MM

92173-0190

$5.33

92173A

CLAMP,10MM

92173-2400

$3.02

92173B

CLAMP

92173-2681

$22.62

92192

TUBE,7X10X440

92192-2275

$16.35

92192A

TUBE,ASWV-A/C

92192-2603

$18.08

92192B

TUBE,ASWV-HEAD CAP

92192-2685

$16.20

92192C

TUBE,BREATHER

92192-2695

$10.43

92200

WASHER,6.5X22X1.6

92200-1087

$3.94

130

BOLT-FLANGED,6X25

130BB0625

$2.80

Kawasaki Ninja ZX-4R ABS Air Cleaner Diagram

FILTER-ASSY-AIR

ELEMENT-AIR FILTER

SCREEN,RAM DUCT

DUCT,RAM AIR

DUCT-ASSY,RAM

PAD

PAD

PAD

VALVE-ASSY,AIR CUT

NUT,WELL,5MM

CLAMP,HOSE CLIP

PLUG,DRAIN

GROMMET

SEAL,ELEMENT

SEAL

SEAL,RAM DUCT

COLLAR,6.5X10.5X13.1

BOLT,UPSET-WP,6X16

BOLT,SOCKET,5X16

DAMPER

DAMPER

CLAMP

SCREW,TAPPING,5X20

SCREW,5X25

CLAMP,20MM

CLAMP,10MM

CLAMP

TUBE,7X10X440

TUBE,ASWV-A/C

TUBE,ASWV-HEAD CAP

TUBE,BREATHER

WASHER,6.5X22X1.6

BOLT-FLANGED,6X25
