Kawasaki Ninja ZX-14R ABS SE Oil Pump/Oil Filter Diagram

Description

Price

13216

GEAR-COMP,OIL COMP

13216-0030

$127.14

14091

COVER,VALVE

14091-0497

$4.92

16085

GEAR,34T

16085-0079

$76.66

16097

FILTER-ASSY-OIL

16097-0008

$11.00

16130

VALVE-ASSY-RELIEF

16130-1059

$37.32

16142

COVER-PUMP

16142-0027

$56.86

16154

ROTOR-PUMP

16154-0047

$28.61

32033

PIPE,OIL FILTER

32033-1535

$9.85

49065

FILTER-OIL

49065-0014

$22.41

51044

TUBE-ASSY

51044-0713

$249.15

92005

FITTING

92005-0752

$146.49

92022

WASHER,13.2X20X0.5

92022-1224

$3.29

92043

PIN,17.9X5.0

92043-1444

$3.85

92055

RING-O,OIL FILTER

92055-1503

$7.25

92066

PLUG

92066-3778

$10.63

92154

BOLT,FLANGED,6X40

92154-1052

$2.44

92154A

BOLT,FLANGED,6X25

92154-1849

$1.81

120

BOLT-SOCKET,6X20

120CA0620

$1.28

610

ROLLER,4X8

610A0408

$3.29

670

O RING,11MM

670D2011

$1.05
