Description

Price

39156

PAD,49X400X0.3

39156-0753

$17.74

39156A

PAD,100X50X5

39156-2543

$2.64

55028

COWLING,SIDE,LH,L.GREEN

55028-0759-777

$242.22

55028A

COWLING,SIDE,RH,L.GREEN

55028-0760-777

$255.31

55028B

COWLING,WINGLET,LH,L.GREEN

55028-0761-777

$280.47

55028C

COWLING,WINGLET,RH,L.GREEN

55028-0762-777

$278.67

55028D

COWLING,LWR,LH,L.GREEN

55028-0763-777

$191.68

55028E

COWLING,LWR,RH,L.GREEN

55028-0764-777

$197.07

55028F

COWLING,FR,LWR,LH

55028-0765

$59.51

55028G

COWLING,FR,LWR,RH

55028-0766

$55.38

55028H

COWLING,INNER,LH

55028-0767

$30.76

55028I

COWLING,INNER,RH

55028-0768

$30.76

92015

NUT,WELL,5MM

92015-1757

$7.29

92039

RIVET,HOLE 8MM

92039-0014

$3.29

92039A

RIVET

92039-0068

$2.97

92075

DAMPER,6X16X7

92075-1011

$7.33

92075A

DAMPER

92075-1067

$4.69

92075B

DAMPER,BOOST SENSOR

92075-2113

$1.15

92152

COLLAR

92152-2740

$6.52

92153

BOLT,SOCKET,6MM

92153-0489

$3.73

92154

BOLT,SOCKET,5X16

92154-0209

$2.75

92154A

BOLT,SOCKET,5X16

92154-1701

$1.19

92161

DAMPER,6X20X7.5

92161-1937

$1.94

92172

SCREW,TAPPING,5X16

92172-0175

$1.78

92200

WASHER,10.4X15.9X0.5

92200-0157

$2.15

92200A

WASHER,5.2X10X1.0

92200-1820

$0.63

92210

NUT

92210-0571

$3.52

130

BOLT-FLANGED,5X12

130BA0512

$2.22

Kawasaki Ninja® ZX™-10RR (US) Cowling Lowers Diagram

PAD,49X400X0.3

PAD,100X50X5

COWLING,SIDE,LH,L.GREEN

COWLING,SIDE,RH,L.GREEN

COWLING,WINGLET,LH,L.GREEN

COWLING,WINGLET,RH,L.GREEN

COWLING,LWR,LH,L.GREEN

COWLING,LWR,RH,L.GREEN

COWLING,FR,LWR,LH

COWLING,FR,LWR,RH

COWLING,INNER,LH

COWLING,INNER,RH

NUT,WELL,5MM

RIVET,HOLE 8MM

RIVET

DAMPER,6X16X7

DAMPER

DAMPER,BOOST SENSOR

COLLAR

BOLT,SOCKET,6MM

BOLT,SOCKET,5X16

BOLT,SOCKET,5X16

DAMPER,6X20X7.5

SCREW,TAPPING,5X16

WASHER,10.4X15.9X0.5

WASHER,5.2X10X1.0

NUT

BOLT-FLANGED,5X12
