Description

Price

11057

BRACKET,FLAP STAY

11057-1276

$69.91

11057A

BRACKET,KEY CYLINDER

11057-1627

$17.30

14093

COVER,HARNESS

14093-0657

$46.97

35019

FLAP

35019-0641

$64.12

35023

FENDER-REAR

35023-0441

$147.93

35023A

FENDER-REAR,HUGGER

35023-0442

$66.60

35023B

FENDER-REAR,TAIL

35023-0443

$49.10

39156

PAD,195X115X1

39156-1884

$25.79

39156A

PAD,15X25X1

39156-2119

$1.84

92015

NUT,LOCK,FLANGED,6MM

92015-1603

$4.69

92039

RIVET

92039-0068

$2.97

92039A

RIVET,3.2X9.5

92039-0752

$0.95

92152

COLLAR,6.5X10X6.2

92152-2152

$3.29

92152A

COLLAR,6.1X13.3X7.5

92152-2462

$12.43

92153

BOLT,SOCKET,6X10

92153-0410

$2.80

92154

BOLT,SOCKET,5X16

92154-0209

$2.75

92154A

BOLT,SOCKET,6X18

92154-1694

$2.75

92154B

BOLT,SOCKET,6X14

92154-1807

$3.29

92154C

BOLT,SOCKET,6X22

92154-1810

$3.86

92154D

BOLT,6X18

92154-3728

$1.71

92161

DAMPER,30X20X2

92161-0833

$1.63

92172

SCREW,TAPPING,5X16

92172-0175

$1.78

92200

WASHER,NYLONE,5.3X11.5X0.5

92200-0006

$1.86

92200A

WASHER,6.2X15X1.2

92200-1762

$1.19

92200B

WASHER,6.5X16X2

92200-1834

$1.00

92200C

WASHER,6.2X15X1.2

92200-1937

$2.44

92200D

WASHER,6.1X14X1

92200-1948

$2.95

Kawasaki NINJA H2™ SX Rear Fender(s) Diagram

BRACKET,FLAP STAY

BRACKET,KEY CYLINDER

COVER,HARNESS

FLAP

FENDER-REAR

FENDER-REAR,HUGGER

FENDER-REAR,TAIL

PAD,195X115X1

PAD,15X25X1

NUT,LOCK,FLANGED,6MM

RIVET

RIVET,3.2X9.5

COLLAR,6.5X10X6.2

COLLAR,6.1X13.3X7.5

BOLT,SOCKET,6X10

BOLT,SOCKET,5X16

BOLT,SOCKET,6X18

BOLT,SOCKET,6X14

BOLT,SOCKET,6X22

BOLT,6X18

DAMPER,30X20X2

SCREW,TAPPING,5X16

WASHER,NYLONE,5.3X11.5X0.5

WASHER,6.2X15X1.2

WASHER,6.5X16X2

WASHER,6.2X15X1.2

WASHER,6.1X14X1
