Kawasaki Ninja® 250R Electro Bracket Diagram

Description

Price

130

BOLT-FLANGED,6X10

130B0610

$0.48

130A

BOLT-FLANGED,8X20

130B0820

$0.67

132

BOLT-FLANGED-SMALL,8X20

132G0820

$3.84

221

SCREW-CSK-CROS,6X25

221E0625

$4.34

11012

CAP,SWING ARM BRACKET

11012-1459

$11.06

11044

BRACKET,AIR FILTER

11044-1828

$15.89

11045

BRACKET,ELECTRIC

11045-1578

$26.47

32098

CASE-TOOL

32098-1076

$28.46

32109

GRIP-FRAME,RR,EBONY

32109-1163-H8

Unavailable

35011

STAY,FR,RH

35011-1355

$141.35

35011A

STAY,MUFFLER,LH

35011-1356

$95.32

35011B

STAY,MUFFLER,RH

35011-1357

$95.32

35011C

STAY,FR,LH

35011-1380

$141.35

53045

HOOK-ASSY,ROPE

53045-1051

$38.87

92001

BOLT,6X14,BLACK

92001-1847

$3.96

92075

DAMPER,ROPE HOOK

92075-1726

$5.59

92150

BOLT,BANK SENSOR

92150-1002

$8.38

92150B

BOLT,SOCKET,8X20

92150-1839

$2.15

92160

DAMPER,BATTERY HOLDER

92160-1500

$14.76
