Honda NCH502AC (14) METROPOLITAN, CHN, VIN# LALAF701-E3100001 TO LALAF701-E3199999 FRONT WHEEL Diagram

#

Description
Price

1

SHOE SET, BRAKE

06450-GFC-770

$31.42

2

TIRE (80/100-10 46J) (DURO)

42711-GFC-904

Unavailable

3

VALVE, RIM

42753-GFC-880

Unavailable

3

VALVE, RIM This part replaces 42753-GFC-902.

42753-GFC-880

Unavailable

4

SPRING, BRAKE SHOE

43151-GC4-000

$4.76

4

SPRING, BRAKE SHOE

45151-GFC-900

$2.92

5

AXLE, FR. WHEEL

44301-GFC-770

$9.15

6

COLLAR, FR. WHEEL SIDE

44311-GFC-900

$7.39

7

COLLAR, FR. DISTANCE

44620-GFC-900

$3.02

8

WHEEL SUB-ASSY., FR. *NH1* (COO) (BLACK)

44650-GGL-305ZA

$139.10

8

WHEEL SUB-ASSY., FR. *NH295M* (COO) (SPARKLING SILVER METALLIC)

44650-GGL-305ZB

$128.08

9

GEAR, SPEEDOMETER (14T) This part replaces 44806-GAZ-930.

44806-GS7-003

$18.68

9

GEAR, SPEEDOMETER (14T)

44806-GS7-003

$18.68

10

PANEL SUB, FR. BRAKE *NH1* (BLACK)

45010-GGL-J00ZA

$90.25

10

PANEL SUB, FR. BRAKE *NH295M* (SPARKLING SILVER METALLIC)

45010-GGL-J00ZC

$83.25

11

SEAL, BRAKE CAM

45134-165-890

$1.57

12

CAM, FR. BRAKE

45141-GGL-J01

$22.95

13

INDICATOR, FR. BRAKE

45145-GFC-900

$2.15

14

ARM, FR. BRAKE

45410-GGL-J00

$16.84

15

SPRING, BRAKE ARM RETURN

45435-GFC-950

$4.03

16

JOINT, BRAKE ARM

45453-GGL-J00

$5.82

17

SPRING, BRAKE CABLE END

45456-GGL-J00

$3.00

18

NUT, BRAKE ADJUSTING

45459-GGL-J00

$10.28

19

NUT, U (10MM) NUT, SELF-LOCK (10MM)

90304-GE8-003

$3.67

20

OIL SEAL (19X30.5X7) (ARAI) This part replaces 90754-GAZ-980.

90754-147-003

$5.31

20

OIL SEAL (19X30.5X7) (ARAI)

90754-147-003

$5.31

21

OIL SEAL (34X42X5) This part replaces 91252-GAZ-980.

91252-GF0-004

$6.16

21

OIL SEAL (34X42X5) (NOK)

91252-GF0-004

$6.16

22

BOLT, HEX. (5X25)

92101-05025-0A

$1.49

23

NUT, HEX. (5MM)

94001-05000-0S

$2.74

24

BEARING, RADIAL BALL (6200U)

96140-62000-10

$15.44
