Description

Price

1

SPRING, OIL THROUGH

15447-149-000

$2.71

2

RUBBER, AIR CLEANER MOUNTING

17227-GS3-000

$2.91

3

NUT, PUSH (6MM)

18316-HW1-671

$0.72

4

RUBBER B, STOPPER

50354-428-000

$2.66

5

COLLAR, SIDE COVER

61104-435-000

$4.83

6

RUBBER, HEADLIGHT CASE MOUNTING

61304-415-000

$3.31

7

SEAT, SINGLE (TYPE1)

77100-MKW-D70ZA

$118.08

8

RUBBER, SEAT SETTING

77206-GF0-000

$5.21

9

LOCK A, SEAT CATCH

77220-MGS-D31

$68.38

10

CABLE, SEAT LOCK

77241-MKW-D71

$13.87

11

ROD, PILLION SEAT

77242-MGS-D30

$26.18

12

STAY

77250-MKW-D70

$17.66

13

PIN, SEAT HINGE

77251-MGS-D30

$6.54

14

ARM, SEAT HINGE

77255-MKW-D70

$22.03

15

SEAT ASSY. (TYPE1)

77300-MKW-D70ZA

$130.47

16

SPRING, SEAT LOCK

77302-MEE-000

$1.99

17

LOCK B, SEAT CATCH

77320-MGS-D31

$53.54

18

BOLT, FLANGE (6X20)

90101-MAS-000

$2.97

19

COLLAR (6.2X12)

90501-MFA-D00

$2.97

20

BOLT-WASHER (6X25)

93404-06025-00

$1.01

21

SCREW, TAPPING (4X12)

93913-14220

$0.84

22

NUT, FLANGE (6MM)

94050-06080

$0.60

23

WASHER, PLAIN (4MM) (Honda Code 0331462)

94101-04800

$0.91

24

WASHER, PLAIN (5MM)

94103-05800
