Ski-Doo MXZ X-RS 600HOE XS RS, 2015 Hydraulic Brakes _22M1542 Diagram

#

Description
Price

1

Carriage Bolt M6 X 1.0 X 16

207761644

$1.74

2

Elastic Stop Nut M6

232561434

$1.55

3

Torx Screw M6 X 16

250000223

$1.74

4

Hex. Button Head Screw M8 X 1.25 X 35

250000764

$1.66

5

Brake Caliper Ass'y | Includes 17 to 17c This part replaces 507032603.

507032501

$470.74

5a

Brake Pads Kit

507032489

$64.32

5b

Brake Spring Kit

507032722

$36.89

5c

Bleeder

507032475

$16.89

5d

BOOT-QTS 20 - Call your local BRP dealership

414989700

Unavailable

6

O-Ring

293300134

$2.25

8

CYLINDER MASTER ASS'Y - Call your local BRP dealership | Includes 6 to 6d

507032511

Unavailable

8a

LEVER - Call your local BRP dealership

507032428

Unavailable

8b

Cap

415029900

$41.51

8c

Pin Ass'y

415030000

$17.66

8d

Microswitch

507032526

$38.43

9

Disk

507032513

$235.35

10

Hose

507032528

$46.12

11

THREADED TUBE - Call your local BRP dealership

507032533

Unavailable

12

Open Clamp

518321570

$6.03

13

Copper Washer

705601628

$4.34

14

Clamp

293650256

$4.36

15

Banjo Bolt

507032551

$5.52

16

DISK PROTECTOR, ALUMINUM - Call your local BRP dealership

507032531

$93.05

17

Banjo Bolt

507032551

$5.52

20

Warning Decal

516005525

Unavailable

21

Clamp And Screw Kit

507032477

$23.05

21a

Clamps | Includes 75a to 75b

719000049

$23.05

21b

Hex. Flange Screw M6 X 25

250000447

$2.06
