Ski-Doo MX Z 500 SB (black), 2000 02- Air Intake System Diagram
#
Description
Price
1
Air Intake Ass'y | Includes 1 - 7. MX Z 500. MX Z 500 SB (Black).
508000070
Unavailable
Air Intake Ass'y | Formula Deluxe 700.
508000106
Unavailable
Air Intake Ass'y | MX Z 700 SB. MX Z 700 SB (Black). MX Z 700 SB Millennium Edition.
508000090
Unavailable
2
INTAKE GRILL - Call your local BRP dealership
508000004
Unavailable
3
Air Intake Adaptor (38 mm) | Formula Deluxe 500.
508000073
Unavailable
Air Intake Adaptor (40 mm)
570068900
Unavailable
4
Lower Foam
508000099
Unavailable
6
CAUTION DECAL, AIR INTAKE - Call your local BRP dealership This part replaces 516001191.
516002715
Unavailable
7
GROMMET - Call your local BRP dealership
570065500
Unavailable
8
Clamp | Formula Deluxe 500.
508000046
Unavailable
Clamp
508000009
Unavailable
10
VM 38-429 Carburetor | Formula Deluxe 500.
403138581
Unavailable
VM 40-128 Carburetor | Formula Deluxe 700.
403138622
Unavailable
VM 40-130 Carburetor | MX Z 700 SB. MX Z 700 SB (Black). MX Z 700 SB Millennium Edition.
403138620
Unavailable
11
Pressure Manifold Ass'y | Includes 11 - 14. MX Z 700 SB. MX Z 700 SB (Black). MX Z 700 SB Millennium Edition.
512059193
Unavailable
12
Pressure Manifold Harness | Includes 4 - 8.
515175271
Unavailable
13
SOLENOID LOCK - Call your local BRP dealership
415061600
Unavailable
15
SUPPORT - Call your local BRP dealership
512058919
Unavailable
18
AIR TEMPERATURE SENSOR - Call your local BRP dealership
270600000
Unavailable
23
Not Available As Spare Part - Friction Washer
Unavailable
24
Not Available As Spare Part - Friction Washer
Unavailable
25
FEMALE TERMINAL - Call your local BRP dealership
409015100
Unavailable
26
PLUG - Call your local BRP dealership
515175303
Unavailable
27
FEMALE HOUSING, 6 CIRCUITS - Call your local BRP dealership
409015400
Unavailable
28
FEMALE LOCK, 6 CIRCUITS - Call your local BRP dealership
409014900
Unavailable
29
HOSE - Call your local BRP dealership
404161880
Unavailable
