Kawasaki MULE PRO-FXR™ 1000 LE Frame Fittings(Rear) Diagram

Description

Price

13272

PLATE,SEAT BACK,UPP

13272-2319

$261.16

13272A

PLATE,SEAT BACK,LWR

13272-4147

$429.99

14093

COVER,RR,FLOOR,MUD,LH

14093-0388

$75.19

14093A

COVER,RR,FLOOR,MUD,RH

14093-0389

$75.19

14093B

COVER,RR SIDE,LH

14093-0591

$87.05

14093C

COVER,RR SIDE,RH

14093-0592

$54.21

14093D

COVER,A/C,RH

14093-0593

$51.71

14093E

COVER,FR ENG

14093-0594

$42.61

27012

HOOK,STRIKER

27012-0806

$2.95

49031

LATCH,TOGGLE

49031-0015

$7.82

92009

SCREW,TAPPING,6X16

92009-1166

$5.52

92027

COLLAR,L=4.6

92027-1168

$5.00

92039

RIVET

92039-0747

$2.49

92039A

RIVET

92039-0865

$0.77

92172

SCREW,6X16

92172-0236

$0.85

92172A

SCREW,6X16

92172-0711

$3.02

92172B

SCREW,TAPPING,6X16

92172-0739

$0.85
