Kawasaki MULE PRO-DXT™ DIESEL Fuel Pump Diagram

#

Description
Price

130

BOLT-FLANGED,6X12

130BA0612

$1.72

13329

SUPPORT

13329-0001

$19.09

14093

COVER,GOVERNOR CASE

14093-0448

$32.41

21188

SOLENOID,POWER CONTROL

21188-0012

$168.90

21188A

SOLENOID,STOP

21188-0013

$201.60

32155

PIPE,FEED

32155-2047

$65.13

32155A

PIPE,RETURN

32155-2048

$65.13

49040

PUMP-FUEL,INJECTION

49040-0751

$3,061.37

51044

TUBE-ASSY

51044-0785

$113.30

92037

CLAMP,HOSE CLIP

92037-1181

$3.36

92038

KEY,WOODRUFF

92038-0008

$4.74

92055

RING-O

92055-0859

$8.36

92055A

RING-O

92055-0860

$2.92

92055B

RING-O

92055-0861

$3.94

92154

BOLT,FLANGED,8X63

92154-1940

$3.63

92154A

BOLT,FLANGED,6X14

92154-1997

$2.49

92154B

BOLT,FLANGED,6X10

92154-2068

$2.03

92154C

BOLT,FLANGED,8X16

92154-2071

$2.03

92170

CLAMP

92170-1938

$3.74

92171

CLAMP

92171-0515

$6.38

92173

CLAMP

92173-1467

$3.29

92192

TUBE,7.5X13.5X390

92192-1476

$47.32

92192A

TUBE,PUMP-FILTER

92192-1477

$19.56

92192B

TUBE,FILER-ENGINE(FILTER SIDE)

92192-1478

$27.48

92192C

TUBE,ENGINE-FILER(ENGINE SIDE)

92192-1479

$58.26

92192D

TUBE,ENGINE-FILER(FILTER SIDE)

92192-1480

$25.88

92192E

TUBE,FILTER-TANK

92192-1481

$66.48

92200

WASHER,SPRING

92200-1810

$2.49

92210

NUT,12MM

92210-1486

$2.92
