Kawasaki MULE PRO-DX™ EPS DIESEL Fuel Pump Diagram
#
Description
Price
130
BOLT-FLANGED,6X12
130BA0612
$1.72
13329
SUPPORT
13329-0001
$19.09
14093
COVER,GOVERNOR CASE
14093-0448
$32.41
21188
SOLENOID,POWER CONTROL
21188-0012
$168.90
21188A
SOLENOID,STOP
21188-0013
$201.60
32155
PIPE,FEED
32155-2047
$65.13
32155A
PIPE,RETURN
32155-2048
$65.13
49040
PUMP-FUEL,INJECTION
49040-0751
$3,061.37
51044
TUBE-ASSY
51044-0785
$113.30
92037
CLAMP,HOSE CLIP
92037-1181
$3.36
92038
KEY,WOODRUFF
92038-0008
$4.74
92055
RING-O
92055-0859
$8.36
92055A
RING-O
92055-0860
$2.92
92055B
RING-O
92055-0861
$3.94
92154
BOLT,FLANGED,8X63
92154-1940
$3.63
92154A
BOLT,FLANGED,6X14
92154-1997
$2.49
92154B
BOLT,FLANGED,6X10
92154-2068
$2.03
92154C
BOLT,FLANGED,8X16
92154-2071
$2.03
92170
CLAMP
92170-1938
$3.74
92171
CLAMP
92171-0515
$6.38
92173
CLAMP
92173-1467
$3.29
92192
TUBE,7.5X13.5X390
92192-1476
$47.32
92192A
TUBE,PUMP-FILTER
92192-1477
$19.56
92192B
TUBE,FILER-ENGINE(FILTER SIDE)
92192-1478
$27.48
92192C
TUBE,ENGINE-FILER(ENGINE SIDE)
92192-1479
$58.26
92192D
TUBE,ENGINE-FILER(FILTER SIDE)
92192-1480
$25.88
92192E
TUBE,FILTER-TANK
92192-1481
$66.48
92200
WASHER,SPRING
92200-1810
$2.49
92210
NUT,12MM
92210-1486
$2.92
