Kawasaki Mule 4010 4x4 Hardwoods Green HD Carrier(s) Diagram
#
11012
CAP
11012-1784
$6.32
11065
CAP
11065-0126
$3.38
13107
SHAFT
13107-0082
$65.41
13168
LEVER
13168-0090
$12.04
13272
PLATE,SIDE,LH,C.H.GREEN
13272-0565-826
Unavailable
13272A
PLATE,SIDE,RH,C.H.GREEN
13272-0566-826
Unavailable
14008
LINER,CARRIER BED
14008-0005
$325.22
14008A
LINER,TAIL GATE
14008-0006
$46.96
27012
HOOK,TAIL GATE
27012-0022
$6.43
35011
STAY,CARRIER STOPPER
35011-1648
$28.90
39156
PAD,TAIL GATE
39156-0042
$8.86
53004
MAT,CARRIER
53004-0031
$115.68
53004A
MAT,CARRIER
53004-0032
$115.68
53004B
MAT,CARRIER
53004-0034
$115.68
53004C
MAT
53004-1159
$116.22
53029
CARRIER,BASE PLATE,BLACK
53029-0063-10
$1,075.88
53045
HOOK-ASSY,TAIL GATE
53045-0004
$29.74
53062
GATE-TAIL,C.H.GREEN
53062-0002-826
$684.97
92009
SCREW,6X12
92009-1480
$3.21
92009A
SCREW,6X14
92009-1662
$3.92
92015
NUT,LOCK 6MM
92015-1262
$5.52
92015A
NUT,FLANGED,8MM
92015-1408
$5.38
92015B
NUT,LOCK,FLANGED,6MM
92015-1675
$4.31
92022
WASHER,8.5X20X1.6,BLACK
92022-1317
$4.31
92022A
WASHER,7X18X1.2
92022-1545
$1.03
92039
RIVET
92039-1229
$1.19
92043
PIN,12X65
92043-1428
$10.09
92075
DAMPER
92075-1817
$6.22
92075A
DAMPER
92075-1882
$8.10
92145
SPRING,TENSIONER
92145-1215
$4.63
92161
DAMPER
92161-0258
$4.16
92190
TUBE,13X16X200
92190-1401
$5.25
130
BOLT-FLANGED,6X30
130BA0630
$1.46
130A
BOLT-FLANGED,8X20
130BB0820
$0.84
130B
BOLT-FLANGED,8X30
130BB0830
$4.49
130C
BOLT-FLANGED,8X50
130BB0850
$4.73
220
SCREW-PAN-CROS,6X10
220AB0610
$1.81
554
PIN-SNAP,12MM
554DA1200
$3.96
