Yamaha MT10NGY (MT10) B5Y20 2022 COWLING 2 Diagram

#

Description
Price

1

DUCT 4

B5Y-2838U-00-00

Unavailable

2

BOLT, FLANGE DEEP RECESS

95E32-06016-00

$0.60

3

COLLAR

90387-06130-00

$9.49

4

DUCT 2

B5Y-2838R-00-00

$28.99

5

BOLT, FLANGE DEEP RECESS

95E32-06016-00

$0.60

6

COLLAR

90387-06130-00

$9.49

7

RIVET

90269-06008-00

$9.49

8

SENSOR, PRESSURE

1WS-82380-00-00

$193.99

9

BOLT

90109-04001-00

$1.75

10

NUT

90179-04003-00

$3.28

11

GROMMET(4FU)

90480-13567-00

$4.99

12

COVER 1

B5Y-2842M-00-00

Unavailable

13

COLLAR (3L1)

90387-07717-00

$8.49

14

BOLT,HEX. SOCKET BUTTON

90111-06199-00

$3.50

15

PLUG(1NL)

90338-07180-00

$7.49

16

BRACKET 11

B5Y-2833H-00-00

Unavailable

17

DAMPER

B67-21488-00-00

Unavailable

18

GROMMET

90480-11006-00

Unavailable

19

COVER 2

B5Y-2842N-00-00

Unavailable

20

COLLAR (3L1)

90387-07717-00

$8.49

21

BOLT,HEX. SOCKET BUTTON

90111-06199-00

$3.50

22

PLUG(1NL)

90338-07180-00

$7.49

23

BRACKET 12

B5Y-2833J-00-00

Unavailable

24

DAMPER

B67-21488-00-00

Unavailable

25

GROMMET

90480-11006-00

Unavailable
