COOLING SYSTEM - W045303CA/IA (4990539053B07)
Polaris MSX 140 - W045303CA/IA COOLING SYSTEM - W045303CA/IA (4990539053B07) Diagram
#
1
Gasket
5812237
Unavailable
2
Fitting, Thru-Hull
5434149-133
Unavailable
3
Fitting, 90 Degree
5133884
Unavailable
4
Hose, Water
5412374
Unavailable
5
Hose, Water
8450054-38
Unavailable
5
Hose, Water
8450054-42
Unavailable
5
Hose, Water
8450054-68
Unavailable
5
Hose, Water
8450054-150
Unavailable
5
Hose, Water
8450054-72
Unavailable
5
Hose, Water
8450054-38
Unavailable
5
Hose, Water
8450054-42
Unavailable
5
Hose, Water
8450054-68
Unavailable
5
Hose, Water
8450054-150
Unavailable
5
Hose, Water
8450054-72
Unavailable
6
Clamp, Hose
7080475
$10.39
6
Clamp, Hose
7080475
$10.39
7
Fitting, Tee
5431784
Unavailable
8
Clamp, Hose
7080476
$6.39
9
Hose, Water, T-Fitting/Pipe
5412377
Unavailable
10
Thermostat, 143 Degrees F.
7051008
Unavailable
11
Valve, Pop-Off
5432799
Unavailable
12
Gasket, Thermostat
5412014
Unavailable
13
Spring, Compression
7042276
Unavailable
14
Washer
7556174
Unavailable
15
Seal, O-Ring Thermostat Fitting
5410860
Unavailable
16
Cover, Thermostat
5631136
Unavailable
17
Fitting
7052156
$30.00
18
Anchor, Cable Tie
7080464
Unavailable
19
CABLE-TIE,DIA12-50MM,WTHR-RES.
7080138
$2.41
20
CABLE-TIE,25-76MM,WEATH.-RES.
7080492
$2.41
21
Conduit, Flex
5521398-60
$5.71
22
Conduit, Wire
5521286-2.5
Unavailable
23
Tubing, Convoluted
8360011-34
$7.99
24
Cable Tie
7080598
Unavailable
25
Conduit, Flex
5521287-117
Unavailable
25
Conduit, Flex
5521287-20
$5.75
26
T-Fitting
7052340
Unavailable
27
Hose, Water
5412376
Unavailable
