Polaris MSX 140 - W045303CA/IA COMPARTMENT DOOR - W045303CA/IA (4990539053A03) Diagram

#

Description
Price

-

Asm., Hinge, Front [Incl. 15,16,18,19,22,23]

2874377

$155.56

1

Windshield, Smoked Grey [If built before 10/23/03]

5434974-412

Unavailable

1

Windshield, Smoked Clear [If built after 10/23/03]

5435307-466

Unavailable

2

Screw

7518042

$5.49

3

Gasket, Mirror, LH

5412344

Unavailable

3

Gasket, Mirror, RH

5412345

Unavailable

3

Gasket, Mirror, LH

5412344

Unavailable

3

Gasket, Mirror, RH

5412345

Unavailable

4

Mirror, Black, LH

2632908-070

$130.95

4

Mirror, Black, RH

2632909-070

$119.05

4

Mirror, Black, LH

2632908-070

$130.95

4

Mirror, Black, RH

2632909-070

$119.05

5

WASHER-6.4MMX18X1.6,SS

7556094

$4.76

5

WASHER-6.4MMX18X1.6,SS

7556094

$4.76

5

WASHER-6.4MMX18X1.6,SS

7556094

$4.76

5

WASHER-6.4MMX18X1.6,SS

7556094

$4.76

5

WASHER-6.4MMX18X1.6,SS

7556094

$4.76

5

WASHER-6.4MMX18X1.6,SS

7556094

$4.76

6

NUT-6 MM X 1.00-NYLOK-SS

7546704

$1.75

6

NUT-6 MM X 1.00-NYLOK-SS

7546704

$1.75

6

NUT-6 MM X 1.00-NYLOK-SS

7546704

$1.75

7

Nut

7546705

$4.76

8

Latch

7081088

Unavailable

9

Washer, Lock

7552613

Unavailable

9

Washer, Lock

7552613

Unavailable

10

Screw

7517528

Unavailable

11

Plunger, Latch (If built after 10/31/03)

5134119

Unavailable

11

Plunger, Latch (If built before 10/31/03)

5133945

Unavailable

12

Washer, Flat (Qty. 2 with 5133945)

7555841

Unavailable

13

Bumper, Rubber, Latch Post

5412299

Unavailable

14

Washer, Flat

7556249

Unavailable

14

Washer, Flat

7556249

Unavailable

15

Nut, Hex, Nylok

7546804

$1.19

15

Nut, Hex, Nylok

7546804

$1.19

15

Nut, Hex, Nylok

7546804

$1.19

16

HINGE, LOWER

----

Unavailable

17

Screw

7518185

Unavailable

18

Washer, Flat

7555835

$0.69

19

Stud, Ball, Threaded

5133640

$11.11

20

Rod End

7061114

Unavailable

20

Rod End

7061114

Unavailable

21

Pin, Dowel

5133641

Unavailable

22

Spring, Gas

7042260

Unavailable

23

HINGE, UPPER

----

Unavailable

24

Bolt

7516807

Unavailable

25

Screw

7518187

$3.97

26

Clip

7080703

$1.10

27

Door, Compartment, Silver Metallic

5434520-445

$545.99

28

Gauge, MFI

3280399

$586.18
