Can-Am Maverick MAX 1000_XDS-DPS, 2015 Rear Suspension _26C1511 Diagram

#

Description
Price

1

Hex. Screw M12 X 80

207028046

$3.25

2

Hex Flange Screw M10 X 80

207608046

$4.46

3

Hex. Flange Screw M12 X 60

207626046

$6.08

4

Hex. Flange Screw M12 X 85

207628546

$5.54

5

Hex. Forming Screw M5 X 16

210251650

$0.92

6

Elastic Stop Nut M12

232521416

$1.40

7

Elastic Stop Nut M18

232591414

$3.48

8

Hex. Flange Elastic Nut M10

233201436

$1.74

9

Elastic Flange Nut M12

233221416

$2.33

10

Hex. Flange Elastic Nut M12

250000047

$1.56

11

Washer M5

250200025

$0.61

12

Washer

250200045

$7.37

13

O-Ring

293300100

$5.52

14

Retaining Ring

293370093

$7.37

17

Grease Fitting 90°

293550056

$1.37

18

Grease Fitting

408200700

$2.80

19

Retaining Ring

706000251

$6.45

21

Sway Bar Lever

706001371

$161.51

25

Radial Joint

706001373

$41.51

28

Sway Bar Housing

706001402

$14.75

30

Ball Joint | Package-STD, XRS, XRSDPS

706001437

$50.74

31

Sway Bar

706001356

$179.97

31

SWAY BAR - Call your local BRP dealership

706001625

Unavailable

36

Ball Joint | Package-STD, XRS, XRSDPS

706001798

$50.74

41

SUSPENSION ARM REAR L B-357 MANTA GREEN - Call your local BRP dealership | Model-Turbo Deep Black

706002225

Unavailable

41

SUSPENSION ARM REAR L B-357 MANTA GREEN - Call your local BRP dealership | Model-Turbo Deep Black

706002225

Unavailable

41

SUSPENSION ARM REAR L B-357 MANTA GREEN - Call your local BRP dealership | Model-Turbo Deep Black

706002225

Unavailable

41

SUSPENSION ARM REAR L B-357 MANTA GREEN - Call your local BRP dealership | Model-Turbo Deep Black

706002225

Unavailable

41

Manta Green RH Rear Upper Arm | Model-Turbo Deep Black

706002226

$193.82

41

Manta Green RH Rear Upper Arm | Model-Turbo Deep Black

706002226

$193.82

41

Manta Green RH Rear Upper Arm | Model-Turbo Deep Black

706002226

$193.82

41

Manta Green RH Rear Upper Arm | Model-Turbo Deep Black

706002226

$193.82

48

Black LH Rear Lower Arm

706001935

$193.82

48

Black RH Rear Lower Arm

706001936

$193.82

61

SHOCK - Call your local BRP dealership

706001947

Unavailable

61b

Spherical Bearing

715900337

$80.74

61d

O-Ring Bushing

715900338

$10.98

61e

CIRCLIP - Call your local BRP dealership

715900339

$10.62

61f

INTERNAL BUSHING - Call your local BRP dealership

715900340

Unavailable

62

SHOCK - Call your local BRP dealership

706001947

Unavailable

62a

Spherical Bearing

715900337

$80.74

62d

O-Ring Bushing

715900338

$10.98

62e

CIRCLIP - Call your local BRP dealership

715900339

$10.62

62f

INTERNAL BUSHING - Call your local BRP dealership

715900340

Unavailable

64

MANTA GREEN SPRING - Call your local BRP dealership | Model-MAVERICK 1000 Deep Black

706001945

Unavailable

64

MANTA GREEN SPRING - Call your local BRP dealership | Model-MAVERICK 1000 Deep Black

706001945

Unavailable

64

MANTA GREEN SPRING - Call your local BRP dealership | Model-MAVERICK 1000 Deep Black

706001945

Unavailable

64

MANTA GREEN SPRING - Call your local BRP dealership | Model-MAVERICK 1000 Deep Black

706001945

Unavailable

64

MANTA GREEN SPRING - Call your local BRP dealership | Model-MAV-MAX

706001948

$87.66

64

Yellow, Rear Spring | Model-MAVERICK Turbo Deep Black

706002108

Unavailable

65

MANTA GREEN SPRING - Call your local BRP dealership | Model-MAVERICK 1000 Deep Black

706001946

Unavailable

65

MANTA GREEN SPRING - Call your local BRP dealership | Model-MAVERICK 1000 Deep Black

706001946

Unavailable

65

MANTA GREEN SPRING - Call your local BRP dealership | Model-MAVERICK 1000 Deep Black

706001946

Unavailable

65

MANTA GREEN SPRING - Call your local BRP dealership | Model-MAVERICK 1000 Deep Black

706001946

Unavailable

65

MANTA GREEN SPRING - Call your local BRP dealership | Model-MAV-MAX

706001949

Unavailable

65

Yellow, Rear Spring | Model-MAVERICK Turbo Deep Black

706002109

Unavailable

92

Adjustment Rod | Package-STD, XRS, XRSDPS

706002081

$46.12

100

LH Double Ball Joint

706002089

$92.28

100

RH Double Ball Joint

706002090

$92.28

102

Hardened Washer

706200281

$2.34

103

Sleeve

706201590

$11.06

104

Suspension Arm Bushing

706204409

$8.29

105

Wear Plate

706201660

$0.89

106

Protector

706202215

$9.23

107

SPRING RETAINER - Call your local BRP dealership

706202216

Unavailable
