Can-Am Maverick MAX 1000_XDS-DPS, 2015 Exhaust System _Turbo_21C1511b Diagram

Hex. Flange Nut M8

233081416

$1.63

Socket Head Screw M10 X 50

250000658

$7.98

Gear Clamp

293650231

$12.97

Hair Pin

414575600

$1.51

Gasket

707600317

$10.52

Spring

707600682

$6.45

Anti-Vibration Rubber

707600702

$8.34

Oxygen Sensor

707600872

$115.67

Seal

707601128

$18.43

FRONT HEAD PIPE - Call your local BRP dealership

707601616

Unavailable

REAR EXHAUST PIPE - Call your local BRP dealership

707602036

Unavailable

Bushing

707601254

$11.06

Head Pipe

707601464

Unavailable

PIPE_EXHAUST OUT WELD - Call your local BRP dealership

707601465

Unavailable

PIPE_EXHAUST IN WELD - Call your local BRP dealership

707601546

Unavailable

Seal

707601565

$36.89

Seal

707601566

$36.89

MUFFLER_EXHAUST - Call your local BRP dealership

707601636

Unavailable
