Polaris MAGNUM 500 2X4 HDS - A02CB50FC OIL TANK (If Built Before 1/02/02) - A02CB50FC (4974857485B11) Diagram

#

Description
Price

1

Screw

7511848

$3.99

2

Plate, Vent, Oil Tank

5211523

$13.99

3

Gasket, Oil Reservoir

5830053

$54.99

4

Fitting

7052163

Unavailable

5

Line, Breather

8450073-85

Unavailable

6

DIPSTICK

5432289

Unavailable

7

O-Ring

5410889

Unavailable

8

Bolt, Banjo

7517102

Unavailable

9

Washer, Copper

7555896

$1.49

10

Tube, Banjo Return

7052302

$45.59

11

Tank, Oil, LH

5131785

$131.99

12

Fitting

7052106

$6.23

13

Hose, Formed

5411036

Unavailable

14

CLAMP-HOSE,.875-SS

7080474

$8.40

15

Bracket, Oil Tank

5245060-067

$5.75

16

SCREW

7517386

$1.49

17

Screen, Oil Filter

2530014

$9.91

18

Nut, Nylok

7542122

$1.49

19

Grommet

5411042

Unavailable

20

GROMMET, MOUNTING, RESERVOIR

5410828

$3.99

21

Bushing

5333204

$26.39

22

Washer, Flat

7558301

$1.49

23

SCREW

7512130

$3.99

24

Plug, Magnetic

7051524

$27.99

25

Washer, Nylon

5850135

$3.19

26

Screw

7515158

$4.79

27

Tank, Oil, RH

5131255

Unavailable
