ENGINE MOUNTING Magnum 4X4 W968144 and Swedish Magnum 4X4 S968144 (4936053605A008)
Polaris MAGNUM 4X4 - W968144 ENGINE MOUNTING Magnum 4X4 W968144 and Swedish Magnum 4X4 S968144 (4936053605A008) Diagram
#
1
NUT LOCK(10)
7542411
$3.19
2
WASHER(10)
7555801
$3.99
2
WASHER(10)
7555801
$3.99
3
CABLE,GROUND/ENG.
4010067
Unavailable
4
MOUNT,RUBBER,TOP
3110044
Unavailable
5
MOUNT,ENG.TOP, BLK.
5240328-067
Unavailable
6
LOCK WASHER(10)
7552901
$1.49
7
BOLT(10)
7512315
$4.79
8
CLAMP-HOSE, (LARGE GREEN) (Large Green)
7080307
$1.49
8
CLAMP-HOSE, (LARGE GREEN) (Large Green)
7080307
$1.49
9
FUEL LINE,1/4 ID(600 CM.)
8450040-600
Unavailable
9
FUEL LINE,1/4 ID(600 CM.)
8450040-600
Unavailable
9
FUEL LINE,1/4 ID(600 CM.)
8450040-600
Unavailable
10
FUEL LINE,1/4 ID(1525 CM.)
8450003-1525
Unavailable
10
FUEL LINE,1/4 ID(1525 CM.)
8450003-1525
Unavailable
11
FITTING, TEE
7052075
$9.59
12
Asm., Screw and Washer (See pg., Ref.)
-------
Unavailable
12
Asm., Screw and Washer (See pg., Ref.)
-------
Unavailable
13
MOUNT,CARB.
3110050
$12.99
14
BRKT, CARB.MT.
5240609-067
Unavailable
15
WASHER(10)
7552605
$5.27
16
NUT HEX(10)
7542105
$3.99
17
Asm., Carburetor (See Pg., Ref.)
-------
Unavailable
18
HOSE CLAMP, RED
7080003
$1.49
18
HOSE CLAMP, RED
7080003
$1.49
18
HOSE CLAMP, RED
7080003
$1.49
18
HOSE CLAMP, RED
7080003
$1.49
19
FUEL LINE,1/8 ID,600 CM.
8360009-600
Unavailable
20
MOUNT,RUBBER,REAR Substituted by 3110068
3110045
Unavailable
21
SCREW(10)
7512490
$3.99
22
WASHER SPRINGLOCK(10) Substituted by 7552603
7553001
Unavailable
23
MT.,SEAL RETAINER,BLK.
5211431-067
Unavailable
24
BOOT,CLUTCH INTAKE
5410421
$11.19
25
CLAMP, NARROW BAND(10)
7080511
$4.79
26
BUSHING-.437 X.770 X.50
5430261
$7.19
27
WASHER-.440X1.25X.190 FL-Y
5210748
$3.99
28
WASHER-7/16-INT LK-(1222)-Z
7575202
$4.79
29
BOLT(10)
7512566
$30.79
30
Asm., Drive Clutch (See Pg., Ref.)
-------
Unavailable
31
BRKT,RETAINER SEAL,BLK. Substituted by 5242046-067
5240409-067
Unavailable
32
MOUNT,RUBBER,FRONT
3110046
Unavailable
33
DECAL,DRAIN RECOIL Substituted by 7078577
7075741
Unavailable
34
CLAMP,HOSE,(10)
7080614
$7.19
34
CLAMP,HOSE,(10)
7080614
$7.19
35
HOSE,WATER,305 CM.
8450050-305
Unavailable
36
Washer, Lock (See Pg., Ref.)
-------
Unavailable
37
Nut (See Pg., Ref.)
-------
Unavailable
38
MANIFOLD Substituted by 1260832-029
1260720-029
Unavailable
39
Gasket Complete (See Pg., Ref.)
-------
Unavailable
40
ENG.(S.B.)EH42PL-01 [No Longer Available]
3085023
Unavailable
41
Hose, Chafe Protection (See Pg., Ref.)
-------
Unavailable
42
NUT LOCK(10)
7542403
$3.99
42
NUT LOCK(10)
7542403
$3.99
