Suzuki LT500R (1987) FRONT FENDER (K/L) Diagram

#

Description
Price

1

FENDER, FRONT (YELLOW)

53111-43B01-25Y

Unavailable

2

FENDER, CENTER (BLUE)

53118-43B00-19F

Unavailable

3

TAPE SET, RH | MODEL K

68150-43B20-25E

Unavailable

4

TAPE SET, LH | MODEL K

68150-43B30-2SE

Unavailable

5

EMBLEM, CENTER FENDER | MODEL K

68151-43B00-2PA

$20.52

5

TAPE SET,FR FEN | MODEL L This part replaces 68150-43B40-3RN.

68150-43B41-3RN

Unavailable

5

TAPE SET, FENDER LH | MODEL L

68150-43B50-3RN

Unavailable

6

BOLT This part replaces 01107-06166.

01500-0616A

$1.78

7

LOCK WASHER This part replaces 08321-21066.

08321-0106A

$1.84

8

WASHER (6.5X20X1.6) This part replaces 09160-06020.

09160-06066

$1.89

9

NUT

53141-19A00

$4.34

10

SCREW This part replaces 02112-06128.

02112-06127

$1.84

11

LOCK WASHER This part replaces 08321-21067.

08321-01067

$2.13

12

WASHER This part replaces 09160-060A6.

09160-06084

$1.78

13

SCREW This part replaces 02142-06164.

02142-0616A

$1.49

14

WASHER (6.5X18X1.6) This part replaces 09160-06039.

09160-06109

$1.49

15

PLATE, CENTER FENDER REAR

53130-43B00

Unavailable

16

SCREW This part replaces 02142-06164.

02142-0616A

$1.49

17

WASHER (6.5X18X1.6) This part replaces 09160-06039.

09160-06109

$1.49

18

NUT

53141-19A00

$4.34

19

BOLT This part replaces 01107-06356.

01500-0635A

$2.19

20

LOCK WASHER This part replaces 08321-21066.

08321-0106A

$1.84

21

.WASHER This part replaces 08322-21066.

08322-0106B

$2.26

22

BRACE, FRONT FENDER

53210-43B00

Unavailable

23

BOLT This part replaces 01107-08125.

01500-0812A

$2.28

24

LOCK WASHER This part replaces 08321-21084.

08321-0108A

$1.84

25

WASHER This part replaces 08322-11084.

08322-0108A

$1.92

26

SCREW This part replaces 02142-06164.

02142-0616A

$1.49

27

WASHER

09169-06037

$2.45

28

LABEL, GEAR SHIFT

68392-22A00

Unavailable

29

LABEL, WARNING MAIN This part replaces 68366-25C00.

68366-20B50

Unavailable

30

LABEL,WARNING This part replaces 68367-41300.

68367-41301

Unavailable

31

LABEL, WARNING

68367-25C00

Unavailable
