Suzuki LT500R (1987) FRONT FENDER (H/J) Diagram

#

Description
Price

1

FENDER, FRONT (YELLOW)

53111-43B01-25Y

Unavailable

2

FENDER, CENTER (BLUE)

53118-43B00-19F

Unavailable

3

TAPE SET | MODEL H

68150-43B00-9BR

Unavailable

3

TAPE SET | MODEL J

68150-43B10-9BR

Unavailable

3

EMBLEM,SUZUKI | MODEL J This part replaces 68111-01C20-9BS.

68111-01C21-9BS

$10.38

4

BOLT, CANISTER This part replaces 01107-06167.

01500-06167

$1.97

5

LOCK WASHER This part replaces 08321-21067.

08321-01067

$2.13

6

WASHER This part replaces 09160-06007.

09160-06084

$1.78

7

NUT

53141-19A00

$4.34

8

SCREW This part replaces 02112-06166.

02112-0616A

$1.49

9

LOCK WASHER This part replaces 08321-21066.

08321-0106A

$1.84

10

WASHER This part replaces 09160-06007.

09160-06084

$1.78

11

SCREW This part replaces 02142-06164.

02142-0616A

$1.49

12

WASHER (6.5X18X1.6) This part replaces 09160-06039.

09160-06109

$1.49

13

PLATE, CENTER FENDER REAR

53130-43B00

Unavailable

14

SCREW This part replaces 02142-06164.

02142-0616A

$1.49

15

WASHER (6.5X18X1.6) This part replaces 09160-06039.

09160-06109

$1.49

16

NUT

53141-19A00

$4.34

17

BOLT This part replaces 01107-06356.

01500-0635A

$2.19

18

LOCK WASHER This part replaces 08321-21067.

08321-01067

$2.13

19

WASHER This part replaces 08322-21067.

08322-01067

$2.13

20

BRACE, FRONT FENDER

53210-43B00

Unavailable

21

BOLT This part replaces 01107-08125.

01500-0812A

$2.28

22

LOCK WASHER This part replaces 08321-21084.

08321-0108A

$1.84

23

WASHER This part replaces 08322-11084.

08322-0108A

$1.92

24

SCREW This part replaces 02142-06164.

02142-0616A

$1.49

25

WASHER (6.5X18X1.6) This part replaces 09160-06039.

09160-06109

$1.49

26

LABEL, GEAR SHIFT

68392-22A00

Unavailable

27

LABEL, WARNING

68366-22A30-8JR

Unavailable

28

LABEL,WARNING This part replaces 68367-04610.

68367-04611

Unavailable
