Description

Price

1

SWINGINGARM SET,REAR

61101-27850

$318.07

2

BUSH, PIVOT

61230-27H00

$70.97

3

HOUSING,RR AXLE This part replaces 61300-27H00.

61300-27H10

$479.75

4

HOUSING,RR AXLE LH

61400-27H00

$260.03

5

BOLT, REAR SWGARM BRACKET (10X20)

09103-10216

$3.96

6

NUT, REAR SWGARM BRACKET

09159-10115

$3.31

7

BOLT, PIVOT (12X80)

09103-12068

$9.08

8

NUT, PIVOT

09159-12054

$9.50

9

O RING, REAR AXLE HOUSING (D:3.1,ID:69.4)

09280-70005

$5.80

10

SEAL, REAR AXLE HOUSING

09283-38022

$12.10

11

BOLT, AXLE HOUSING (10X30)

09103-10421

$4.75

12

CLIP This part replaces 08331-4155A.

08331-41559

$3.49

13

BEARING, HUB

08123-60067

$27.08

14

ABSORBER ASSY, REAR SHOCK (BLACK) | MODEL K8/K9

62100-27H00-019

$221.97

14

ABSORBER ASSY, REAR SHOCK (BLACK) | MODEL L0

62100-27H10-019

$221.63

15

BOLT, LOWER (10X48)

09103-10126

$4.21

16

WASHER, UPPER, OUTER

09160-10501

$2.40

17

NUT

08319-3110B

$4.20

Suzuki LT-F400FK9 (2010) REAR SWINGINGARM Diagram
