Description

Price

1

PLATE, FRONT BRAKE RH

54511-02C00

$49.73

1

PLATE, FRONT BRAKE LH

54811-02C00

Unavailable

2

BOLT, PLATE (6X8)

09100-06157

$2.97

3

LOCK WASHER This part replaces 08321-01063.

08321-0106A

$1.83

4

SHOE SET, FRONT BRAKE

54400-02810

$33.15

5

SPRING

09443-07025

$1.68

6

PLATE, LINING INDICATOR

54492-02C00

Unavailable

7

CAM, FRONT BRAKE

54441-02C00

$24.57

8

O RING (ID:13.8,D:1.90)

09280-14004

$1.67

9

LEVER, FRONT BRAKE CAM RH

54451-02C00

$28.40

9

LEVER, FRONT BRAKE CAM LH

54461-02C00

$28.40

10

BOLT, CAM LEVER (6X32)

09103-06135

$2.77

11

NUT This part replaces 08316-10063.

08316-1006B

$2.50

12

SPRING, CAM LEVER RETURN RH

54484-02C00

$10.78

12

SPRING, CAM LEVER RETURN LH

54494-02C00
