1996 Suzuki LT-4WD Starter Clutch Diagram

← All diagrams

Find the part on the Starter Clutch diagram for your 1996 Suzuki LT-4WD, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

1996 Suzuki LT-4WD Starter Clutch Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

1

GEAR, STARTER IDLE (NT:13/49) This part replaces 12611-19B00.

12611-19B02

1
Out of stock

2

PIN

09206-13016

1
Out of stock

3

SPACER

09180-13009

1
Out of stock

4

CLUTCH SET, STARTER | Includes Item(s) 5

12600-19810

1
Out of stock

5

BEARING

09263-25049

1
Out of stock

6

3

$3.13

In stock
