Suzuki LS650P (2004) CRANK BALANCER Diagram

#

Description
Price

1

BALANCER, CRANK

12651-24B01

Unavailable

2

GEAR, BALANCER DRIVEN

12666-24B01

Unavailable

3

RACE, INNER | MODEL T/V This part replaces 12669-24B00.

12669-24B01

Unavailable

3

RACE, INNER | MODEL W/X/Y/K1/K2/K3/K4

12669-24B01

Unavailable

4

KEY

09420-04008

$3.42

5

SPRING

09440-09031

$2.98

6

PIN

09202-04017

$3.78

7

WASHER (20X54X2)

09166-20010

Unavailable

8

SHIM (20X28X0.5) | MODEL T This part replaces 08221-20285.

09181-20158

$3.03

8

WASHER | MODEL V/W/X/Y/K1/K2/K3/K4

09181-20158

$3.03

9

BEARING (20X47X14)

09262-20089

$29.53

10

BOLT This part replaces 01500-10163.

01500-1016B

Unavailable

11

WASHER

08211-10285

$3.49
