FRONT WHEEL/HUB/TIRE ('79-'80 B3/B4)
Kawasaki KZ1000 LTD FRONT WHEEL/HUB/TIRE ('79-'80 B3/B4) Diagram
#
Description
Price
1
COLLAR,FRONT AXLE
41069-033
Unavailable
2
GEAR BOX ASSY
41078-008
Unavailable
2
GEAR BOX ASSY,SPEEDO
41078-1012
$171.28
3
PIN,SPRING
41082-001
$3.92
4
WASHER,5.1X9X0.4
41063-001
$4.69
5
PINION,SPEEDOMETER
41060-017
Unavailable
6
BUSHING,SPEEDOMETER CABLE
41062-005
$19.48
6
BUSHING,SPEEDOMETER
92028-1066
$11.29
7
GEAR-METER SCREW,26T
41059-026
$42.53
8
SEAL-OIL,BJN30427-C3
92049-1057
$9.28
9
AXLE,FRONT
41068-049
$132.80
10
BOLT
92001-158
$3.41
11
WASHER,LOCK
92088-023
$11.60
12
DUST COVER
41042-014
Unavailable
13
RECEIVER,GEAR
41064-013
Unavailable
14
BEARING-BALL,#6203ZZC3
601B6203ZZ
Unavailable
15
COLLAR,FR HUB BEARIN
92027-1043
Unavailable
16
RING-SNAP,40MM
92033-1040
$5.90
17
OIL SEAL
654A254008
$25.75
18
DUST COVER
41042-015
Unavailable
19
COLLAR,FRONT AXLE
41069-032
$26.55
20
TIRE-FRONT
41021-071
Unavailable
21
TUBE 350/375/410-19
41022-046
Unavailable
22
SOLID WHEEL ASSY,FRNT
41073-1040
$800.70
23
BALANCER-WHEEL,10G
41075-1011
Unavailable
24
BALANCER-WHEEL,20G
41075-1012
Unavailable
25
BALANCER-WHEEL,30G
41075-1013
Unavailable
