Kawasaki KX™450F Frame Fittings Diagram
#
11056
BRACKET,DIAG CONNECTOR
11056-0070
$8.07
11056A
BRACKET,REGULATOR
11056-7457
$16.56
11056B
BRACKET,CONDENSOR
11056-7458
$6.20
11056C
BRACKET,BANK SENSOR
11056-7459
$7.30
11056D
BRACKET,COUPLER
11056-7460
$7.30
11056E
BRACKET,ECU
11056-7985
$58.23
130
BOLT-FLANGED,8X14
130CA0814
$1.48
132
BOLT-FLANGED-SMALL,6X10
132BA0610
$1.71
132A
BOLT-FLANGED-SMALL,6X14
132BA0614
$1.46
32190
BRACKET-ENGINE,FR
32190-0698
$16.56
32190A
BRACKET-ENGINE,UPP,LH
32190-0699
$26.78
32190B
BRACKET-ENGINE,UPP,RH
32190-0700
$26.78
55020
GUARD,ENGINE,SIDE,RH
55020-1892
$30.70
55020A
GUARD,ENGINE,LWR
55020-1893
$27.78
92015
NUT,LOCK,FLANGED,6MM
92015-1339
$1.35
92015A
NUT,8MM
92015-1432
$6.57
92019
NUT,LOCK,6MM
92019-008
$4.26
92045
BEARING-BALL,608LLU/2A
92045-0060
$32.61
92122
ROLLER,CHAIN GUIDE
92122-0016
$18.57
92122A
ROLLER,CHAIN
92122-0042
$15.80
92143
COLLAR
92143-1962
$6.22
92150
BOLT,FLANGED,6X27
92150-1124
$4.87
92152
COLLAR
92152-0459
$26.30
92152A
COLLAR,8.5X12.5X12.5
92152-0944
$6.69
92152B
COLLAR,12.7X27.2X12
92152-0945
$8.58
92152C
COLLAR,8.5X14X7.5
92152-2092
$9.04
92154
BOLT,FLANGED,10X137
92154-0522
$9.73
92154A
BOLT,FLANGED,10X124
92154-0523
$15.95
92154B
BOLT,FLANGED,8X122
92154-0524
$11.27
92154C
BOLT,FLANGED,6X9
92154-0546
$3.74
92154D
BOLT,SOCKET,6X10
92154-0774
$1.63
92154E
BOLT,FLANGED,8X35
92154-1746
$1.48
92154F
BOLT,FLANGED,10X32
92154-1747
$8.05
92161
DAMPER
92161-0266
$1.78
92200
WASHER,8.0X22.0X1.5
92200-0174
$2.61
92210
NUT,LOCK,FLANGED,10MM
92210-1080
$10.28
92210A
NUT,LOCK,10MM
92210-1184
$6.11
