Kawasaki KV100-A7 FRAME/FRAME FITTINGS ('70-'73) Diagram
#
Description
Price
1
FRAME
32002-041
Unavailable
1
FRAME
32002-058
Unavailable
1
FRAME
32002-064
Unavailable
2
CASE BATTERY
32097-015
$27.00
2
CASE-BATTERY
32097-024
$28.33
3
BOX TOOL
32098-011
$24.48
4
CAP-TOOL CASE
32099-005
Unavailable
5
PIN COTTER 2.0X30
550D2030
$1.51
6
MAT BATTERY
32103-013
$1.69
6
MAT-BATTERY
32103-024
Unavailable
7
BOLT,FLANGED,10X115
92001-1603
$10.65
7
BOLT,FLANGED,10X115
92001-1603
Unavailable
8
NUT-HEX-FINE,10MM
314B1000
$0.67
9
WASHER SPRING 10MM
461F1000
$0.67
10
GUARD ENGINE
55011-010
Unavailable
11
BRACKET ENG GUARD
55012-002
Unavailable
12
BOLT-UPSET,6X12
112G0612
$1.45
13
WASHER PLAIN 6MM
411B0600
$2.84
14
WASHER SPRING 6MM
461F0600
$0.69
15
BOLT-UPSET,6X16
112G0616
$1.10
16
BAND
92072-012
$7.34
16
BAND-BATTERY
92072-037
Unavailable
17
DAMPER RUBB FUEL TANK
92075-050
$6.61
18
NUT STEERING STEM LCK
92090-006
$15.04
19
CAP,STEERING STEM
46098-004
$6.16
20
RACE,UPPER BEARING
92047-005
$12.12
21
RACE,BEARING
92048-004
$11.51
22
BALL-STEEL,3/16
600A0600
$1.07
23
WASHER LOCK 6MM
463H0600
Unavailable
24
SPRING-RETURN
92083-017
Unavailable
25
PIN-COTTER,2.5X35
550D2535
$1.52
26
LOCK ASSY-STEERING
27016-029
$28.99
28
SPRING,STEERING LOCK
27032-001
$5.25
29
CAP,STEERING LOCK
11012-1134
$6.87
30
WASHER,WAVE
92097-003
$4.50
31
SCREW,3.51MM
92008-007
$4.11
