Find the part on the Frame Fittings diagram for your 2019 Kawasaki KLX450R, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2019 Kawasaki KLX450R Frame Fittings Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

130

BOLT-FLANGED,5X10

130BA0510

1

$1.47

In stock

130A

BOLT-FLANGED,8X18

130CA0818

1

$2.10

In stock

14079

HOLDER-ASSY,BATTERY

14079-0026

1

$38.22

In stock

32190

BRACKET-ENGINE,FR

32190-0330

1

$49.45

In stock

32190A

BRACKET-ENGINE,FR

32190-0331

1

$49.45

In stock

32190B

1

$30.16

In stock

32190C

1

$30.16

In stock

39184

1

$15.93

In stock

55020

GUARD,ENGINE,RH,EBONY

55020-0179-6C

1

$29.93

In stock

55020A

GUARD,ENGINE,LH,EBONY

55020-0313-6C

1

$29.93

In stock

55020B

GUARD,SKID

55020-0369

1

$40.61

In stock

92015

1

$1.20

In stock

92015A

NUT,8MM

92015-1432

1

$5.21

In stock

92045

1

$33.22

In stock

92122

ROLLER,CHAIN GUIDE

92122-0016

1

$14.60

In stock

92143

COLLAR

92143-1196

1

$3.72

In stock

92143A

COLLAR

92143-1307

1

$3.14

In stock

92150

BOLT,6X12

92150-1435

1

$3.43

In stock

92152

COLLAR

92152-0459

1

$24.68

In stock

92152A

COLLAR,10.2X20X10

92152-0595

1

$3.51

In stock

92153

BOLT,6X20

92153-0502

1
Out of stock

92153A

BOLT,FLANGED,10X35

92153-0802

1
Out of stock

92153B

BOLT,FLANGED,8X35

92153-1652

1

$4.14

In stock

92153C

BOLT,FLANGED,8X126

92153-1870

1

$11.42

In stock

92154

BOLT,FLANGED,10X130

92154-0517

1
Out of stock

92154A

BOLT,FLANGED,10X137

92154-0522

1

$9.42

In stock

92161

DAMPER

92161-0456

1

$4.95

In stock

92210

NUT,LOCK,FLANGED,10MM

92210-1080

1
Out of stock

92210A

NUT,LOCK,10MM

92210-1184

1
Out of stock
