2004 Kawasaki KLX400R (Canada Only) Under Bracket Diagram

← All diagrams

Find the part on the Under Bracket diagram for your 2004 Kawasaki KLX400R (Canada Only), then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2004 Kawasaki KLX400R (Canada Only) Under Bracket Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

13070

1

$10.64

In stock

13070A

GUIDE,CLUTCH CABLE

13070-S026

1

$4.92

In stock

13070B

GUIDE,CABLE

13070-S028

1

$44.80

In stock

13070C

GUIDE,HOSE

13070-S029

1

$27.08

In stock

44037

HOLDER-FORK UNDER

44037-S006

1

$626.71

In stock

44039

HOLDER-FORK UPPER

44039-S005

1

$297.34

In stock

46012

HOLDER-HANDLE

46012-S004

1

$34.42

In stock

92045

1

$70.86

In stock

92153

BOLT

92153-S061

1

$2.27

In stock

92153A

BOLT,6X10

92153-S331

1

$4.17

In stock

92153B

BOLT,8X35

92153-S351

1

$4.25

In stock

92153C

BOLT

92153-S352

1

$6.68

In stock

92200

WASHER

92200-S179

1
Out of stock

92200A

WASHER

92200-S198

1
Out of stock

92210

NUT,STEERING

92210-S131

1
Out of stock

92210A

NUT

92210-S141

1
Out of stock
