Find the part on the Rear Hub diagram for your 2025 Kawasaki KLX230SM ABS, then match its number to the list below. Each line shows the OEM part number, price per piece and stock status. Click a number on the drawing to jump straight to its line. If a part shows up more than once in the assembly, order as many as you need.

2025 Kawasaki KLX230SM ABS Rear Hub Diagram

#

Description
Qty in Assembly
Price
Status
Order Qty

41034

DRUM-ASSY,RR

41034-0612

1
Out of stock

41068

AXLE,RR,15X275

41068-0648

1
Out of stock

42041

SPROCKET-HUB,43T

42041-0190

1
Out of stock

92015

NUT,CASTLE,14MM

92015-1765

1
Out of stock

92049

SEAL-OIL

92049-0114

1
Out of stock

92057

CHAIN,DRIVE,520VF2X106L

92057-0800

1
Out of stock

92058

JOINT-CHAIN

92058-0069

1
Out of stock

92152

COLLAR

92152-2545

1
Out of stock

92152A

COLLAR,15.2X20X96.2

92152-2546

1
Out of stock

92154

BOLT,FLANGED,8X30

92154-3918

1
Out of stock

92200

WASHER,14.2X26X3.2

92200-1428

1
Out of stock

92210

NUT,8MM

92210-0570

1
Out of stock

410

WASHER-PLAIN-SMALL,8MM

410AA0800

1
Out of stock

550

PIN-COTTER,3.0X35

550AA3035

1
Out of stock

601

BEARING-BALL

601B6202UU

1
Out of stock
