Kawasaki KLX150L (Latin America) Side Covers/Chain Cover Diagram

Description

Price

36001A

COVER-SIDE,LH,EBONY

36001-0625-6C

$38.64

36001C

COVER-SIDE,RH,EBONY

36001-0626-6C

Unavailable

36014

CASE-CHAIN

36014-0560

$17.48

39137

STAY-COMP,LH,P.SILVER

39137-0620-458

Unavailable

39137A

STAY-COMP,RH,P.SILVER

39137-0663-458

Unavailable

39156

PAD

39156-0813

$1.93

49089A

SHROUD-ENGINE,LH,UPP,EBONY

49089-0868-6C

Unavailable

49089C

SHROUD-ENGINE,RH,UPP,EBONY

49089-0869-6C

Unavailable

49089D

SHROUD-ENGINE,LH,LWR,L.GREEN

49089-0870-290

Unavailable

49089E

SHROUD-ENGINE,LH,LWR,EBONY

49089-0870-6C

Unavailable

49089F

SHROUD-ENGINE,RH,LWR,L.GREEN

49089-0871-290

$42.39

49089G

SHROUD-ENGINE,RH,LWR,EBONY

49089-0871-6C

Unavailable

92009

SCREW,6X10

92009-1729

$0.22

92075

DAMPER

92075-1629

$5.00

92152

COLLAR,6.3X8.3X9.2

92152-1725

$5.98

92152A

COLLAR,8.8X16X4

92152-1731

$5.65

92152B

COLLAR,6.6X9X4

92152-1982

Unavailable

92152C

COLLAR,8.8X16X4

92152-2185

$5.65

92154

BOLT,FLANGED,6X10

92154-0459

$7.65

92154A

BOLT,FLANGED,6X22

92154-1184

$3.90

92154B

BOLT,FLANGED,6X14

92154-1231

$2.97

92161

DAMPER,8X16X8.6

92161-0685

$6.61

92172

SCREW,6X10

92172-0098

$2.80

92172B

SCREW,5X12

92172-1095

$0.63
