Kawasaki KLX150L (Latin America) Gear Change Drum/Shift Fork(s) Diagram

Description

Price

13140

FORK-SHIFT,INPUT

13140-0066

$48.52

13140A

FORK-SHIFT,OUTPUT RH

13140-0067

$48.52

13140B

FORK-SHIFT,OUTPUT LH

13140-0068

$48.52

13141

DRUM-CHANGE

13141-0572

$79.54

13145

CAM-CHANGE DRUM

13145-0045

$43.54

13151

SWITCH-COMP,NEUTRAL

13151-1099

$3.96

13183

PLATE,CHANGE

13183-1066

$16.01

49047

ROD-SHIFT

49047-1094

$5.56

510

KEY-WOODRUFF

510A3200

$2.70

551

PIN-DOWEL,3X6

551A0306

$1.34

92045

BEARING-BALL,17X35X10

92045-0126

$22.42

92065

GASKET,10.5X16X1

92065-058

$3.96

92154

BOLT,UPSET,6X20

92154-1166

$1.71

92200

WASHER,6.5X24X2

92200-0838

$1.97
